Mindman Air Units

Specification

• Operating pressure range :0~15 kgf/cm2(0~1.5MPa)
• Proof pressure :20 kgf/cm2(2MPa)
• Standard type: 1~8.5 kgf/cm2(0.1~0.85MPa)
• High pressure type: 1~15 kgf/cm2(0.1~1.5MPa)

Specification

• Port size: PT1/4, PT3/8, PT1/2,
• Operating pressure range: 0~9.9 kgf/cm2,
• Proof pressure:15 kgf/cm2

Specification

• Operating pressure range :0~9.9 kgf/cm2 (0~0.99MPa)
• Proof pressure :15 kgf/cm2 (1.5MPa)
• Ambient temperature :5~ 60 (No freezing)
• Weight :250 g

Specification

• Operating pressure range :0~9.9kgf/cm2 (0~0.99MPa)
• Proof pressure :15kgf/cm2 (1.5MPa)
• Regulated pressure range :0.5~8.5kgf/cm2 (0.05~0.85MPa)
• Ambient temperature :5~ 60 (No freezing)

Specification

• Repeatability :Within 0.5% of full span
• Operating pressure range :0~9.9 kgf/cm2 (0~0.99MPa)
• Ambient temperature :5~ 60 (No freezing)
• Weight :300g

Specification

• Operating pressure range :0~9.9 kgf/cm2 (0~0.99 MPa)
• Proof pressure :15 kgf/cm2 (1.5 MPa)
• Effective orifice :32mm2, 34mm2
• Ambient temperature :5~ 60 (No freezing)
