Air units (Auto-drainer)

Get a Price/Quote

MOQ : 1 Piece

Air units (Auto-drainer) Specification

Shape
Cylindrical

Machine Type
Air Preparation Units

Size
Standard (custom sizes available)

Method
Mechanical Float/Timer Controlled

Load Capacity
Handles System Pressure Up to 10 Bar

Accuracy
Reliable Automatic Drainage

Weight
Approx. 200-350 g

Thread Type
BSP/NPT Standard

Hardness
Medium (Depends on Component)

Coating
Anti-corrosive Coating

Type
Auto-drainer

Material
Plastic and Metal

Tolerance
Standard

Surface
Smooth Finish

Use
Air Units

Application
Compressed Air Systems, Industrial Automation

Usage & Applications
Automatic moisture drainage from air compressors and filters

Inlet/Outlet Connection
1/4" to 1/2" BSP/NPT

Temperature Range
5C to 60C

Operating Pressure Range
1-16 Bar

Mounting Orientation
Vertical

Flow Rate
Up to 1500 L/min

Media
Compressed Air

Installation
Inline with Air System

Drain Type
Automatic

Color
Silver/Gray (Body), Black (Cap)

Drain Port Size
6 mm, 8 mm, 10 mm

Maintenance
Low, Easy to Clean

About Air units (Auto-drainer)

Air units (Auto-drainer)

Clean compressed air, extends the life of pneumatic equipmentNo electricity required

Features

Clean compressed air, extends the life of pneumatic equipment
No electricity required
Easy installation not limited by space

Specifications :

Dimensions	6 4 8 (150mm 100mm 200mm)
Inlet	PT 1/2
Outlet	PT 1/2
Automatic outlet	PT 3/8, 5/16 HOSE
Operating pressure range	20-125 psig(1.3-8.8 kg/cm2),40-180 psig(3-12.7 kg/cm2)
Ambient temperature	36~140 (2~60 )
Min. equipment requirement	180 l/min (about l HP),250 l/min (about 2 HP)
Max. condensate discharge rate	15 gal/hour (57 l/min),12 gal/hour (46 l/min)
Bowl	Polycarbonate (PC),Aluminium
Weight	2.9 lbs.(1.3kg),3.1 lbs.(1.4kg)

Automatic Drainage Efficiency

These auto-drainers are designed to eliminate manual intervention in draining moisture from air compressors and filters. Thanks to mechanical float or timer-controlled operation, they ensure an uninterrupted flow and protect equipment from water damage, optimizing system reliability and operational uptime.

Versatile Installation and Compatibility

Supporting BSP/NPT standard threads, our units fit seamlessly into a wide range of compressed air systems. The cylindrical design and vertical mounting orientation make integration straightforward, minimizing installation time and expense for distributors, importers, and suppliers.

FAQs of Air units (Auto-drainer):

Q: How does the auto-drainer operate in a compressed air system?

A: The auto-drainer functions automatically, using a mechanical float or timer mechanism to detect and expel accumulated water from air compressors and filters. This helps maintain optimal system performance without manual intervention.

Q: What are the benefits of installing an auto-drainer in industrial automation?

A: Installing an auto-drainer in industrial automation ensures reliable moisture removal, which increases equipment lifespan, reduces downtime due to water-related issues, and sustains consistent air quality for efficient processes.

Q: When should the auto-drainer be cleaned or maintained?

A: These units have a low maintenance requirement and are easy to clean. Routine inspection and cleaning should be scheduled as part of standard system maintenance, especially in high-humidity or high-usage environments.

Q: Where should the auto-drainer be mounted in an air system?

A: For best results, the auto-drainer should be mounted vertically and installed inline with the air system, close to compressors or main air filters where moisture accumulation is prevalent.

Q: What applications are suitable for this auto-drainer?

A: This product is ideal for compressed air systems in industrial automation, providing automatic moisture drainage for air compressors and filters in manufacturing plants, workshops, and other industries.
