Auto Drain Valves

Get a Price/Quote

MOQ : 1 Piece

Auto Drain Valves Specification

Method
Electronic/Timer Based or Float Operated

Size
1/4 inch, 1/2 inch, 3/8 inch (varies by model)

Coating
Anti-corrosive Plating on Metal Parts

Thread Type
BSP/NPT Standard Thread

Load Capacity
Pressure Range: Up to 16 bar (232 psi)

Weight
250-550 g

Accuracy
High precision draining, less than 1% manual intervention

Machine Type
Auto/ Electric Condensate Drainage

Shape
Cylindrical

Hardness
65-75 Shore D (plastic), Up to 80 HRB (metal)

Type
Auto Drain Valve

Material
Plastic and Metal

Tolerance
±0.05 mm

Surface
Smooth, Corrosion-resistant Finish

Use
Automatic draining of condensate from air compressors and compressed air systems

Application
Pneumatic systems, Air compressors, Industrial automation

Usage & Applications
Removes accumulated liquids automatically; suitable for industrial and commercial compressed air applications

Ingress Protection
IP65 (suitable for industrial environment)

Drain Duration
0.5 sec to 10 sec adjustable

Connection Type
Threaded

Product Lifespan
Over 1 million cycles (valve operation)

Cycle Time
Adjustable (0.5 min to 45 min)

Maximum Temperature
Up to 60°C

Maintenance
Self-cleaning / Minimal maintenance required

Operating Voltage
220V AC / 110V AC / 24V DC

Drain Port Diameter
6 mm to 10 mm

Installation Position
Vertical (recommended)

Auto Drain Valves About

Find the celebrated, top-ranking Auto Drain Valves designed for industrial excellence and optimal performance. Engineered for unassailable reliability, each valve supports 220V AC, 110V AC, or 24V DC operation, with a robust 6-10 mm drain port and IP65 ingress protectionideal for challenging environments. Personalise your order choosing from multiple thread types and port sizes. With a smooth, corrosion-resistant surface and anti-corrosive plating, these cylindrical valves promise over one million operational cycles. Grab yours today for automatic, precise condensate removal with minimal maintenance and maximum durability.

Versatile Features and Advanced Usage Applications

Auto Drain Valves deliver seamless, automatic removal of condensate from pneumatic systems and air compressors. Crafted with a corrosion-resistant finish and anti-corrosive coated metal parts, these valves offer versatility for industrial automation, commercial sites, and OEM machine integration. Their self-cleaning function and minimal maintenance requirements make them ideal for continuous use in demanding environments. Used as an electronic, timer-based, or float-operated device, they reliably support high-precision draining for a wide range of industrial needs.

Certifications, Quotations, and Ordering Process

All our Auto Drain Valves comply with rigorous industry standards and certifications, ensuring safety and quality in every unit. To initiate your purchase, request a quotation detailing your requirements. Sale price and payment terms are shared during the quotation phase, with sample units available upon request. Order completion is efficient, and our distribution network covers India for rapid delivery. Secure your industrial system with confidence through our streamlined order process.

FAQs of Auto Drain Valves:

Q: How do Auto Drain Valves enhance condensate removal in compressed air systems?

A: Auto Drain Valves automatically discharge accumulated liquids from air compressors and pneumatic systems, greatly reducing manual intervention and maintaining optimal air quality.

Q: What installation position is recommended for these Auto Drain Valves?

A: Vertical installation is recommended for optimal drainage efficiency and to ensure reliable performance over prolonged operation.

Q: When should the cycle time and drain duration be adjusted?

A: Cycle time and drain duration should be personalised based on the frequency and volume of condensate formed. Adjustment ranges cater to dynamic industrial requirements for precise, automated operation.

Q: Where can these Auto Drain Valves be used?

A: They are suitable for a wide array of industrial and commercial applications, including air compressors, pneumatic systems, and automated machinery across various sectors.

Q: What is the typical process for ordering these Auto Drain Valves?

A: Start by requesting a quotation for your preferred specifications. Upon agreement on the sale price and payment terms, sample units can be provided. Bulk orders are processed swiftly through our distributor network across India.

Q: What are the primary benefits of the anti-corrosive plating and self-cleaning design?

A: Anti-corrosive plating protects the metal components from harsh environments, while the self-cleaning design ensures long-term performance and minimises required maintenance, delivering a reliable, cost-effective solution.
