Solenoid Valve MVSZ Series Model: MVSZ-100

Send Inquiry

Request To Call Back

Solenoid Valve MVSZ Series Model: MVSZ-100

Get a Price/Quote

MOQ : 1 Piece

Solenoid Valve MVSZ Series Model: MVSZ-100 Specification

Method
Solenoid Actuation

Weight
Lightweight

Shape
Rectangular

Size
Standard

Type
Solenoid Valve

Material
Aluminum Alloy

Surface
Smooth

Use
Industrial Automation

Application
Pneumatic Systems

Usage & Applications
Control of Pneumatic Flows

About Solenoid Valve MVSZ Series Model: MVSZ-100

Solenoid Valve MVSZ Series

Model: MVSZ-100

Body width:10 mm, Port size:M5 0.8, Operating pressure range:1.5~7 kgf/cm², Proof pressure:10 kgf/cm², Flow: 208 Nl /min

Specifications :

Bore No.

Port size

M50.8

No. of port

No. of position

Medium

Air

Operating pressure range

1.5~7 kgf/cm²

Proof pressure

10 kgf/cm²

Effective orifice

4.68 mm² (0.26 Cv)

Response time

17 ms

Ambient temperature

5~50

Voltage

AC110V, AC220V(50/60)Hz, DC6/12/24V

Power consumption

AC=1.6 / 2.5VA, DC=1.2W (LED indicator)

Available voltage range

10%

Insulation class

F class

Weight

40 g

Efficient Pneumatic Flow Control

The MVSZ-100 solenoid valve facilitates precise and rapid control of air flow within pneumatic systems, enhancing operational reliability. Its lightweight aluminum alloy body and smooth surface finish contribute to easier handling and maintenance, making it suitable for continuous industrial automation processes.

Versatile Integration and Durability

Designed to fit standard pneumatic setups, this valves rectangular form and aluminum alloy construction deliver both strength and versatility. Industries benefit from its long-lasting performance and compatibility with various equipment, improving operational uptime and productivity.

FAQs of Solenoid Valve MVSZ Series Model: MVSZ-100:

Q: How does the MVSZ-100 solenoid valve function in pneumatic systems?

A: The MVSZ-100 operates by using electrical current to actuate a solenoid, which then controls the opening or closing of the valve, regulating air flow in pneumatic systems with high precision.

Q: What are the notable benefits of using a lightweight aluminum alloy solenoid valve in industrial automation?

A: Using a lightweight aluminum alloy valve like the MVSZ-100 minimizes installation stress, reduces overall system weight, and offers reliable durability, meeting the demands of continuous industrial automation.

Q: When should the MVSZ-100 solenoid valve be used within pneumatic applications?

A: The MVSZ-100 is ideal for applications requiring precise, rapid air flow control and is most beneficial in automated industrial environments where efficient pneumatic regulation is necessary.

Q: Where can the Model MVSZ-100 be installed for optimal performance?

A: This valve is best installed in standardized pneumatic flow control systems within manufacturing, processing, or automation facilities where reliability and compatibility are essential.

Q: What is the process for integrating the MVSZ-100 into an existing pneumatic system?

A: Integration involves mounting the standard-size valve onto the systems flow line, connecting its electrical actuator, and calibrating it according to the desired pneumatic flow control parameters.

Q: How does the rectangular design of the MVSZ-100 benefit its usage in industrial setups?

A: The rectangular shape enables straightforward installation and alignment with compatible equipment, reducing setup time and enhancing mechanical stability in operation.

Q: What advantages does the MVSZ-100 provide distributors, importers, and suppliers?

A: Distributors, importers, and suppliers can offer the MVSZ-100 as a versatile, durable, and efficient pneumatic control solution that easily meets the requirements of various industrial automation clients.
