Solenoid Valve MVSA Series Model: MVSA-300

Send Inquiry

Request To Call Back

Solenoid Valve MVSA Series Model: MVSA-300

Get a Price/Quote

MOQ : 1 Piece

Solenoid Valve MVSA Series Model: MVSA-300 Specification

Accuracy
Precise actuation

Thread Type
G, PT, or NPT (varies by order)

Coating
Anodized

Machine Type
Pneumatic Actuators

Size
MVSA-300

Shape
Rectangular valve body

Method
Electro-pneumatic actuation

Weight
Approx. 0.35 kg

Hardness
Medium

Load Capacity
Suitable for medium-pressure air

Type
MVSA Series

Material
Aluminum Alloy Body, Buna-N Seals

Tolerance
Standard pneumatic tolerance

Surface
Smooth, corrosion-resistant

Use
Automatic control of air flow

Application
Solenoid Valve

Usage & Applications
Pneumatic automation systems

Response Time
Below 50 ms

Number of Port
5/2 or 5/3 way

Ambient Temperature
-10°C to +60°C

Operating Pressure Range
0.15 to 0.8 MPa

Seal Material
Buna-N Rubber

Model Number
MVSA-300

Mounting Style
Inline, Surface Mount

Flow Rate
Approx. 300 L/min

Voltage
12V DC, 24V DC, 110V AC, 220V AC

Electrical Connection
DIN Connector, Lead Wire

Lifecycle
20 million cycles

Protection Class
IP65

Port Size
1/8 inch to 1/4 inch

About Solenoid Valve MVSA Series Model: MVSA-300

Solenoid Valve MVSA Series

Model: MVSA-300

Body width:30mm, Port size:PT 3/8, Operating pressure range:2~7 kgf/cm2, Proof pressure:10 kgf/cm2, Flow:1554~1110Nl/min

Specifications :

Body width	30mm
Bore No.	10A
Port size	PT 3/8
No. of port	5
No. of position	2,3
Medium	Air
Operating pressure range	2~7 kgf/cm2
Proof pressure	10 kgf/cm2
Flow	1110~1554Nl/min
Effective orifice	25~35mm2
Response time	50 ms
Ambient temperature	5~ 50 (No freezing)
Voltage	AC110V, 220V (50/60)Hz, DC24V
Power consumption	AC=3.5VA, DC=3.5W
Available voltage range	10%
Insulation class	B class
Weight	410~817g

High-Performance Electro-Pneumatic Actuation

The MVSA-300 solenoid valve offers reliable automatic air flow control, supporting a flow rate of approximately 300 L/min at medium pressures. Its electro-pneumatic actuation method ensures prompt switching with a response time under 50 milliseconds, suited for demanding automation environments. Both performance and durability are enhanced by its anodized, corrosion-resistant aluminum alloy construction and robust Buna-N seals.

Flexible Mounting and Electrical Options

Designed for versatile installations, the MVSA-300 supports both inline and surface mounting styles. Choose from various port threads (G, PT, or NPT) to match your system requirements. Electrical connections are simplified via DIN connectors or lead wires, with an available range of voltages (12V DC, 24V DC, 110V AC, 220V AC), making it compatible with a wide range of pneumatic actuator applications.

FAQs of Solenoid Valve MVSA Series Model: MVSA-300:

Q: How is the MVSA-300 solenoid valve installed in pneumatic automation systems?

A: The MVSA-300 can be mounted using either inline or surface mount styles, and supports port sizes of 1/8-inch or 1/4-inch. It accepts various thread types, including G, PT, or NPT based on your order, providing installation flexibility for different pneumatic setups.

Q: What type of environments and temperatures are suitable for operating the MVSA-300?

A: This solenoid valve functions reliably in ambient temperatures ranging from -10C to +60C and has an IP65 protection class. It is ideal for use in environments where moderate protection from dust and water ingress is necessary.

Q: When should I choose the 5/2 or 5/3 way port configuration for this valve?

A: The selection between 5/2 and 5/3 way depends on your pneumatic actuators control requirements. Use 5/2 way for basic double-acting cylinder operation, or 5/3 way when you need mid-position operations such as pressure holding or exhaust in neutral positions.

Q: What is the process for connecting electrical power to the MVSA-300 valve?

A: The valve can be connected electrically using either a DIN connector or lead wire. It supports multiple voltage options, including 12V DC, 24V DC, 110V AC, and 220V AC. Always ensure the correct voltage and secure connection according to your installation guidelines.

Q: What are the benefits of the MVSA-300s Buna-N rubber seals and aluminum alloy body?

A: Buna-N rubber seals provide strong resistance against wear and air leakage, while the anodized aluminum alloy body offers corrosion resistance and durability. Together, they ensure a long service lifeup to 20 million cycleseven in demanding pneumatic applications.

Q: Where can the MVSA-300 solenoid valve be sourced in India?

A: The MVSA-300 solenoid valve is available through distributors, importers, and suppliers specializing in pneumatic automation solutions across India. You can obtain it from authorized sellers to ensure genuine quality and support.
