MINDMAN MCBQI2 series

Get a Price/Quote

MOQ : 1 Piece

MINDMAN MCBQI2 series Specification

Coating
Anodized for corrosion resistance

Method
Double acting, compact cylinder

Accuracy
High repeatability 0.01 mm

Thread Type
Metric threads

Size
Bore size: 20mm - 63mm (multiple options)

Weight
Varies by model, approx. 0.3kg to 1.2kg

Cutting Speed
N/A (not a cutting component)

Load Capacity
Maximum 1.0 MPa (10.2 kgf/cm^2)

Hardness
High strength with durable build

Shape
Rectangular

Machine Type
Pneumatic

Type
Compact Air Cylinder

Material
Aluminium alloy

Tolerance
0.01 mm

Surface
Polished, smooth finish

Use
Industrial automation

Application
Actuator for pneumatic systems

Usage & Applications
Automated machinery, robotics, assembly lines

Max. Pressure Resistance
1.5 MPa

Port Size
M5x0.8 or 1/8" (depends on bore size)

Stroke Length
10mm ~ 100mm (varies by model)

Series
MCBQI2

End Cover Material
Aluminum alloy with surface treatment

Seal Material
Nitrile rubber (NBR)

Operating Temperature
-5°C to +60°C

Piston Speed
50~500 mm/sec

Minimum Operating Pressure
0.1 MPa

Mounting Type
Through hole and threaded mount

Working Medium
Filtered compressed air

Cushion Type
Rubber cushion at both ends

About MINDMAN MCBQI2 series

Experience the formidable performance of the MINDMAN MCBQI2 Series. This distinguished compact air cylinder is engineered for industrial automation, robotics, and assembly lines. Shop Now for options with through hole or threaded mounting, stroke lengths from 10mm to 100mm, and multiple bore sizes (20mm63mm). The advance purchase opportunity enables you to personalise specifications for your automation needs. With a spectacular polished finish, high-strength aluminium alloy construction, and resilient nitrile seals, this actuator delivers precision, reliability, and corrosion resistance, making it a standout choice for demanding CNC and pneumatic applications.

MINDMAN MCBQI2 Series: Advantage and Use Case

The MINDMAN MCBQI2 series boasts distinguished durability and precision, advancing your automated machinery with compact design and reliable performance. Its high-strength anodized aluminium body ensures premium corrosion resistance, while the double-acting method supports formidable repeatability (0.01 mm). Ideal for industrial automation, this cylinder handles demanding tasks in robotics, assembly lines, and CNC machining, making it the preferred choice for users seeking high-grade actuators and robust usage in dynamic manufacturing environments.

Sample Policy and Delivery Details for the MCBQI2 Series

Request a comprehensive quotation for your MINDMAN MCBQI2 sample needs. Our premium packaging guarantees safe drop-off of every compact cylinder. Standard delivery time is efficient, ensuring your order arrives promptly for advance assembly and integration. Each unit is wrapped with care to maintain its spectacular finish and structural integrity throughout transit. For full details, connect with our team for tailored packaging and fulfilment insights that match your personalised industrial automation requirements.

FAQs of MINDMAN MCBQI2 series:

Q: How do I choose the correct stroke length and bore size for my MCBQI2 cylinder?

A: Select stroke length (10mm to 100mm) and bore size (20mm to 63mm) based on your applications load and movement needs. Consult specifications or request guidance for ideal performance.

Q: What is the working temperature and pressure range for the MCBQI2 series?

A: The operating temperature ranges from -5C to +60C, with pressure tolerance from 0.1 MPa minimum up to a maximum resistance of 1.5 MPa, ensuring adaptability for varied industrial settings.

Q: Where is the MCBQI2 series most commonly applied?

A: It is primarily used in industrial automation, such as robotics, assembly lines, and as actuators in pneumatic systems due to its high accuracy and durable build.

Q: What makes the MCBQI2 series suitable for CNC applications?

A: High accuracy (0.01 mm), robust anodized aluminium construction, and compatibility with CNC processes make this cylinder ideal for precise automation tasks.

Q: How does the sample ordering process work for the MCBQI2 series?

A: Submit a quotation request to receive sample details. All items are shipped with premium protective packaging, ensuring secure and prompt drop-off at your specified location.
