Mindman MCGD series

Get a Price/Quote

MOQ : 1 Piece

Mindman MCGD series Specification

Method
Double Acting Pneumatic Cylinder

Accuracy
High Precision Gripping

Machine Type
Pneumatic Gripper

Weight
Varies by Model (e.g., MCGD16: 90g, MCGD40: 510g)

Thread Type
Metric

Size
MCGD16, MCGD20, MCGD25, MCGD32, MCGD40

Coating
Hard Anodized

Hardness
60-65 HRC

Shape
Rectangular

Load Capacity
10N to 196N (depends on model)

Type
Parallel Style Pneumatic Gripper

Material
High-grade Aluminum Alloy

Tolerance
0.01mm

Surface
Anodized/Sandblasted/Polished

Use
Industrial Automation

Application
Pneumatic Grippers and Automation Handling

Usage & Applications
Pick & Place, Assembly, Material Handling

Opening/Closing Stroke
4mm to 16mm (Depending on model)

Grip Force
10~196N

Ambient Temperature
-10°C~60°C

Jaw Material
Steel (hardened) with optional custom jaws

Mounting
Multiple Sides, with Through-holes and Tapped Holes

Acting Type
Double Acting

Sensor Slot
Available for Magnetic Sensors

Repeatability
±0.01mm

Port Size
M5 x 0.8 or 1/8" BSP (depending on model)

Seal Type
High-quality NBR Seals

Life Cycle
Over 10 million cycles (under ideal conditions)

Operating Pressure
0.1~0.7 MPa

Lubrication
Factory-lubricated, Maintenance-free

About Mindman MCGD series

MCGD series
TUBE I.D.
STROKE
STROKE=10mm	MCGD-03
	MCGD-23
STROKE=20mm	MCGD-03
	MCGD-23
STROKE=25mm	MCGD-03
	MCGD-23
STROKE=30mm	MCGD-03
	MCGD-23
STROKE=40mm	MCGD-03
	MCGD-23
STROKE=50mm	MCGD-03
	MCGD-23
STROKE=75mm	MCGD-03
	MCGD-23
STROKE=100mm	MCGD-03
	MCGD-23
STROKE=125mm	MCGD-03
	MCGD-23
STROKE=150mm	MCGD-03
	MCGD-23
STROKE=175mm	MCGD-03
	MCGD-23
STROKE=200mm	MCGD-03
	MCGD-23

Precision Gripping for Automation Efficiency

The MCGD Series achieves exceptional accuracy, offering 0.01mm repeatability and grip forces ranging from 10N to 196N, depending on the model. Its double acting pneumatic cylinder ensures firm and consistent handling of materials, making it an ideal solution for demanding assemblies or pick-and-place operations.

Reliable and Versatile Mounting Options

Each unit features multiple mounting sides with both through-holes and tapped holes, catering to varied layout requirements and ensuring integration flexibility. Magnetic sensor slots are incorporated for easy sensor addition, providing reliable position feedback for automated processes.

Durable Construction for Long Service Life

Built with high-grade aluminum alloy and hardened steel jaws, MCGD Series grippers are engineered for durability and strength. Coated surfaces, including anodized, sandblasted, or polished finishes, enhance their resistance to wear and corrosion, supporting over 10 million cycles under ideal conditions.

FAQs of Mindman MCGD series:

Q: How do I choose the appropriate MCGD Series model for my automation application?

A: Select the MCGD model based on required grip force, opening/closing stroke, load capacity, and working environment. Model sizes range from MCGD16 to MCGD40, each with specific stroke, force, and port size options. Consider the part size and weight for accurate selection.

Q: What benefits does the MCGD Series offer for industrial automation?

A: The MCGD Series delivers high-precision gripping with repeatability of 0.01mm, robust construction, and maintenance-free operation. Its versatility in mounting, sensor compatibility, and long life cycle ensures reliable performance and minimal downtime in automated production lines.

Q: When is the maintenance required for these pneumatic grippers?

A: The MCGD Series grippers are factory-lubricated and designed to be maintenance-free, thanks to high-quality NBR seals and durable components. Maintenance is only required under abnormal operating conditions or at the end of their rated life cycle, which exceeds 10 million cycles.

Q: Where can I install the MCGD Series pneumatic gripper within my automation system?

A: You can mount the MCGD Series on various sides using supplied through-holes or tapped holes, giving flexibility in installation on robotic arms, linear slides, or fixed handling modules. Their rectangular shape fits seamlessly into automation setups.

Q: What is the process for integrating magnetic sensors with the MCGD series?

A: The grippers are equipped with sensor slots specifically designed for easy installation of magnetic sensors. Simply insert compatible sensors into the slot to enable position feedback for precise automation control.

Q: How does the double acting mechanism benefit gripping operations?

A: The double acting pneumatic cylinder enables controlled and reliable opening and closing of the gripper jaws, providing consistent grip force during every cycle. This ensures secure handling of workpieces in fast-paced industrial environments.

Q: What level of durability and hardness do the MCGD Series jaws offer?

A: The jaws are manufactured from hardened steel with a surface hardness rating of 6065 HRC and feature an optional custom jaw configuration. This assures exceptional durability for repetitive tasks and protection against wear, extending gripper service life.
