HI MORE INJECTION MOULDING ROBOT ZH SERIES

Get a Price/Quote

MOQ : 1 Piece

HI MORE INJECTION MOULDING ROBOT ZH SERIES Specification

Coating
Anti-Rust Coated

Accuracy
High Repeatability, 0.1 mm

Size
Varies by Model (ZH-650, ZH-1300, ZH-1800 etc.)

Shape
Robotic Arm (Articulated)

Load Capacity
Up to 3-5 kg (Typical)

Method
Automatic; Programmable Logic Controlled

Machine Type
Horizontal Injection Moulding Robot

Weight
Depends on Model; Generally Lightweight for Fast Operation

Hardness
Industrial Standard

Type
Injection Moulding Robot (ZH Series)

Material
High Grade Alloy & Engineering Plastics

Tolerance
High Precision

Surface
Smooth Finish Body

Use
Injection Moulding Automation

Application
Plastic Moulding Industry

Usage & Applications
Automated Removal of Moulded Parts; Insert Placement; Product Stacking

Series
ZH Series

Installation Method
Direct Mount on Injection Moulding Machine

Drive System
Precision Servo Motor & Pneumatics

Color
White & Blue

Robot Arm Reach
650 mm to 1800 mm (Model Dependent)

Maintenance
Low Maintenance Requirements

Operation Mode
Manual/Automatic/Semi-Automatic

Power Supply
AC 220V/380V, 50/60Hz

Axis Control
3-Axis / 5-Axis (Depending on Model)

Control System
User-Friendly HMI Touch Screen

Cycle Time
Short Cycle, High-Speed Operation

Safety Features
Emergency Stop, Safety Interlocks

About HI MORE INJECTION MOULDING ROBOT ZH SERIES

ITEM	ZH-800 II	ZH-1000 II
X-axis Stroke (entry) (mm)	800	1000
Y-axis Stroke (kick) (mm)	400	400
Min. Distance b/w Main Arm to Frame	75	75
Max. Travel Distance of Y Axis from Frame	530	530
Gripper Angle)	90	90
Max. Payload (KG)	1	1
Working Air Pressure	0.5
Power Supply (v)	Single phase AC200 (50Hz/60Hz)

Optimized Automation for the Plastic Moulding Industry

The ZH Series enhances productivity in plastic injection moulding with robust automation for part removal, insert placements, and stacking. Its articulated robotic arm and high-speed drives ensure efficient cycle times while maintaining excellent repeatability and accuracy. With models designed for various machine sizes, the series suits diverse injection moulding setups and enables manufacturers to streamline their operations without compromising precision.

User-Friendly and Flexible Control Interface

Equipped with a modern HMI touch screen, the ZH Series provides easy operation and extensive programmability. The interface allows users to switch between manual, automatic, and semi-automatic modes, adapting quickly to changing production requirements. Easy-to-use menus help operators set up processes, monitor system status, and initiate emergency safety stops, promoting both safety and efficiency in busy factory settings.

FAQs of HI MORE INJECTION MOULDING ROBOT ZH SERIES:

Q: How does the ZH Series robot improve injection moulding automation?

A: The ZH Series robot automates repetitive tasks such as the removal of moulded parts, insert placement, and product stacking. By integrating with existing injection moulding machines, it increases throughput, reduces manual labor, and enhances consistency through high-precision, programmable operations.

Q: What are the available axis configurations and how do they affect performance?

A: The ZH Series comes in 3-axis and 5-axis variants. The additional axes provide greater flexibility and movement range, enabling more complex pick-and-place tasks and accommodating intricate mould layouts. Your choice depends on application requirements and mould complexity.

Q: When should I use the manual, automatic, or semi-automatic modes?

A: Manual mode is suitable for setup and troubleshooting tasks; automatic mode is ideal for continuous, high-volume production; and semi-automatic mode balances operator involvement with automation for processes that require occasional adjustments or monitoring.

Q: Where can the ZH Series robot be installed?

A: This series is designed for direct mounting on horizontal injection moulding machines, making it suitable for new installations as well as upgrades in existing facilities across the plastic moulding industry.

Q: What safety measures are implemented with the ZH Series robot?

A: The robot features emergency stop buttons and safety interlocks to prevent unintended operation, ensuring safe use for operators and maintenance personnel during both setup and routine operation.

Q: How often does the ZH Series require maintenance?

A: Thanks to its robust construction using high-grade alloys, anti-rust coating, and engineering plastics, the ZH Series demands minimal maintenance. Regular inspections and cleaning are recommended, but no extensive upkeep is generally necessary.

Q: What benefits does the ZH Series offer over manual labour?

A: Using the ZH Series results in faster cycle times, improved production accuracy (0.1 mm repeatability), reduced risk of workplace injuries, and consistent output quality. Automation leads to lower operational costs and higher overall efficiency.
