TPI Precision Bearings 7201 C

Get a Price/Quote

MOQ : 1 Piece

TPI Precision Bearings 7201 C Specification

Retainer
Phenolic Resin

Inside Diameter
12 mm

Lubrication Type
Grease/Oil

Thickness
10 mm

Cage Material
Phenolic Resin

Precision Rating
ABEC 7

Bearing Type
Angular Contact Ball Bearing

Material
Steel

Structure
Angular Contact

Seals Type
Open

Number Of Rows
Single Row

Bore Size
12 mm

Outside Diameter
32 mm

Limiting Speed
29500 RPM (Grease) 43300 RPM (Oil)

Load Capacity
1170 lbf (Dynamic) 670 lbf (Static)

Warranty
Manufacturer Warranty

About TPI Precision Bearings 7201 C

TPI Pecision Bearings 7201 C

Bearing Preload..Rigidity..and Measured Face Side Offset

Bearing No

Bore d (mm)

Preload

Rigidity

Measured

Preload

Rigidity

Measured

Preload

Rigidity

Measured

Preload

Rigidity

Measured

Pro

Rao

offset

Pro

Rao

offset

Pro

Rao

offset

Pro

Rao

offset

(N)

(N/ u m )

( u m )

(N)

(N/ u m )

( u m )

(N)

(N/ u m )

( u m )

(N)

(N/ u m )

( u m )

7201C

(-4 )

115

( -14)

220

(-24)

Engineered for Superior Performance

The TPI 7201 C angular contact ball bearing is meticulously crafted to deliver high rotational accuracy in challenging environments. Its ABEC 7 precision rating assures reduced runout and superior efficiency. The phenolic resin retainer supports lighter weight and better heat dissipation, making it suitable for high-speed operations. Reliability and durability are increased through strict quality control by the manufacturer.

Versatile Lubrication and Applications

This bearing accommodates both grease and oil lubrication, adapting to various operational conditions. Opting for oil enables higher RPMs and efficient cooling, while grease offers maintenance simplicity for moderate speeds. Its open design is ideal for machinery where continuous lubrication and cooling are feasible. This flexibility suits industries such as automation, machine tools, and precision spindles.

FAQs of TPI Precision Bearings 7201 C:

Q: How is the TPI 7201 C bearing typically used in industrial applications?

A: It is commonly utilized in machine tool spindles, automation equipment, and high-speed machinery that demand precise angular contact and stable performance at elevated speeds.

Q: What are the benefits of choosing a phenolic resin cage for this bearing?

A: The phenolic resin cage is lightweight, provides excellent heat resistance, and minimizes friction at high rotational speeds, enhancing the bearings performance and longevity under demanding conditions.

Q: When should you opt for oil instead of grease lubrication with this bearing?

A: Oil lubrication is preferred for applications requiring higher speeds (up to 43,300 RPM) and continuous cooling. Grease is suitable for standard operations where lower maintenance is desired.

Q: What process should be followed for installing the 7201 C bearing to ensure optimal performance?

A: During installation, ensure the bearing is handled carefully to avoid contamination, use appropriate mounting tools, and follow the manufacturers guidelines for lubrication and preload settings.

Q: Where can this bearing be sourced as a distributor, importer, or supplier?

A: As an authorized distributor, importer, or supplier, TPI bearings can be purchased through industrial supply networks, authorized TPI agents, or specialized bearing distributors.

Q: What is the primary benefit of the bearings ABEC 7 precision rating?

A: The ABEC 7 rating ensures minimal runout, elevated rotational accuracy, and consistent performance, making the bearing suitable for precision-driven and high-speed applications.
