THK JAPAN Ball Spline
The Ball Spline is a rolling guide spline bearing. This is an innovative product with a ball rolling on a groove connected to the shaft, realizing allowable loads greater than with linear bushing and enabling torque transmission while making linear movements.
THK Medium Torque Model LT
This Ball Spline has a large load capacity in the radial and torque directions since the spline shaft has 2 to 3 crests on the circumference, each held by 2 rows (4 or 6 rows in total) of balls under a load in order to reasonably provide a preload
LT series: LT 4, LT 5, LT 6, LT 8, LT 10, LT 13, LT 16, LT 20, LT 25, LT 30, LT 40, LT 50, LT 60, LT 80, LT 100
LF series: LF 6, LF 8, LF 10, LF 13, LF 16, LF 20, LF 25, LF 30, LF 40, LF 50
