SKF SYSTEM 24 LAGD 125 Single Point Automatic Lubricators

Get a Price/Quote

MOQ : 1 Piece

SKF SYSTEM 24 LAGD 125 Single Point Automatic Lubricators Specification

Lubrication Type
Gas Driven Single Point

Bearing Type
Automatic Lubricators

Material
Transparent polyamide housing, Metal base

Structure
Single Point Automatic Lubricator

Warranty
Up to 12 months

Application
Bearings, chains, slides, gears, open gears, linear guides

Features
Reliable lubrication, easy installation, transparent for visual check, maintenance-free operation

Capacity
125 ml

Discharge Rate
1 to 12 months (adjustable)

Refillable
No, disposable unit

Maximum operating pressure
5 bar

Model
SKF SYSTEM 24 LAGD 125

Operating temperature range
-20C to +60C

Mounting
Threaded connection 1/4 BSP

Activation
Gas driven, self-activating

About SKF SYSTEM 24 LAGD 125 Single Point Automatic Lubricators

SKF SYSTEM 24

The units are supplied ready-to-use straight from the box and filled with a wide range of high performance SKF lubricants. Tool-free activation and time-setting allow easy and accurate adjustment of lubrication flow.

Flexible dispense rate from 1 to 12 months
Stoppable or adjustable if required
Intrinsic safety rating: ATEX approved for zone 0
Transparent lubricant container allows visual inspection of dispense rate
Compact size, permits installation in restrictive areas
Greases and chain oils available
software helps to calculate the correct dispense rate

Typical applications

Applications in restrictive and hazardous locations
Bearing housing lubrication
Electric motors
Fans and pumps
Conveyors
Cranes
Chains (oil)
Elevators and escalators (oil)

Effortless Lubrication Anywhere

The SKF SYSTEM 24 LAGD 125 ensures automatic, continuous lubrication wherever precise maintenance is critical. Its compact, versatile design and threaded connector allow for easy installation on various equipment, including bearings, chains, and linear guides. This system is ideal for those looking to reduce manual intervention and streamline their lubrication schedules.

Adjustable and Reliable Performance

With an adjustable discharge rate between 1 and 12 months, the SKF SYSTEM 24 LAGD 125 adapts to different operational needs. Its self-activating gas-driven mechanism maintains a pressure of up to 5 bar, ensuring reliable lubrication delivery even in challenging environments. Maintenance teams can confidently rely on its consistent performance every cycle.

Transparent, Maintenance-Free Monitoring

The transparent polyamide housing of the SKF SYSTEM 24 LAGD 125 enables quick visual checks of lubricant levels at a glance. As a maintenance-free and disposable unit, there is no need for laborious refilling. Simply install, monitor visually, and replace the unit when depleted for seamless equipment care.

FAQs of SKF SYSTEM 24 LAGD 125 Single Point Automatic Lubricators:

Q: How does the SKF SYSTEM 24 LAGD 125 automatic lubricator operate?

A: The SKF SYSTEM 24 LAGD 125 is activated by a gas-driven mechanism that provides a consistent lubricant discharge. Once installed and set to your preferred discharge rate, it automatically supplies lubrication over 1 to 12 months, eliminating the need for manual greasing.

Q: What types of equipment can this lubricator be used on?

A: The LAGD 125 is suitable for a wide range of applications, including bearings, chains, slides, gears, open gears, and linear guides. Its universal threaded connection enables easy mounting across various types of industrial equipment.

Q: When should the LAGD 125 unit be replaced?

A: Replace the unit when it is empty, which typically occurs after the discharge period you have setanywhere between 1 and 12 months depending on your chosen rate. As a disposable product, it is not refillable and should be replaced with a new unit for continued lubrication.

Q: Where can the LAGD 125 be installed?

A: This lubricator can be mounted directly onto lubrication points via its 1/4 BSP threaded connection. It is suitable for use in environments with temperatures from -20C to +60C.

Q: What is the process for installing the SKF SYSTEM 24 LAGD 125?

A: Installation involves screwing the lubricator into the appropriate lubrication point and activating the unit as per the included instructions. No special tools or skills are required, and it is designed for straightforward placement on various types of machinery.

Q: What are the primary benefits of using this automatic lubricator?

A: Benefits include maintenance-free operation, reduced manual labor, accurate and consistent lubrication, easy installation, and visual monitoring of lubricant levels through its transparent housing. This helps ensure optimal machine performance and prolonged equipment lifespan.
