SCHMIDT COUPLINGS DL MODEL

SCHMIDT COUPLINGS DL MODEL
SCHMIDT COUPLINGS DL MODEL
Product Code : 650
Brand Name : SCHMIDT
Product Description

dl COUPLING  with different shaft centers that use the crank motion of a link. Power input at one end disc is transmitted via a link and center disc to another end disc.The amount of eccentricity is determined by the length of the link. Power can be transmitted smoothly when shaft centers are different. And since power is transmitted by the crank motion of the link, translation of shaft centers during rotation is possible.

Model

No. of links

Parallel mm

Rated torque Nm

Max. rotation speed min-1

Moment of inertia kgm2

Mass kg

DL 7.7-02

2×2

±2

93

2000

7.75×10-4

1.1

DL 7.9-03

2×2

±3

135

1800

2.30×10-3

1.7

DL 10.12-04

2×2

±4

402

1600

9.98×10-3

4.4

DL 13.14-04

2×2

±4

706

1400

2.60×10-2

9.1

DL 16.16-04

2×2

±4

1230

1200

5.10×10-2

13.9

DL 20.20-04

2×2

±4

2310

1000

1.44×10-1

24.1
