Rexroth R1662

Get a Price/Quote

MOQ : 1 Piece

Rexroth R1662 Specification

Weight
Varies by Version (approx. 0.46 kg to 1.5 kg)

Thickness
Compact Height (varies by size)

Material
Steel

Ball Bearing Type
Ball Rail System

Structure
Linear Guide

Seals Type
Double Sealed

Number Of Rows
4 Rows

Limiting Speed
Up to 5 m/s

Rail Width
Standard sizes: 15, 20, 25, 30, 35 mm

Model
R1662

Interchangeability
Yes, compatible with standard guides

Application
Linear Motion for Industrial Automation, CNC, Robotics

Carriage Type
Runner Block, Ball Carriage

Lubrication
Integrated Lubrication Ports

Precision Class
P, H, SP, UP (according to ISO)

Mounting Type
Top or Bottom Mount

Standard Compliances
DIN, ISO

Guide Rail Material
Hardened Steel

Length
Available on Request/Custom Cut

Rexroth R1662 Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
1 Days

About Rexroth R1662

Rexroth R1662

Super Runner Block with self-aligning feature
Runner block 1662-

Slimline short

Special version:
Runner blocks in accuracy class N (clearance and preload 0.02 C) are also available:
- with low friction seals
(part numbers 16..-..4-11)

Dynamic characteristics
SpeedV_max=3m/s
Accelerationa_max=250m/s²

Size	Accuracy class	Part numbers for runner blocks		Downloads
Size	Accuracy class	up to approx. 10 um clearance	Preload 0.02 C	Downloads
15	H	1662-193-10	1662-113-10
15	N	1662-194-10	1662-114-10
20	H	1662-893-10	1662-813-10
20	N	1662-894-10	1662-814-10
25	H	1662-293-10	1662-213-10
25	N	1662-294-10	1662-214-10
30	H	1662-793-10	1662-713-10
30	N	1662-794-10	1662-714-10
35	H	1662-393-10	1662-313-10
35	N	1662-394-10	1662-314-10

Precision and Versatility for Industrial Needs

Engineered to meet ISO and DIN standards, the Rexroth R1662 runner block provides reliable linear motion across industries. Its interchangeable design easily fits existing standard rails, delivering high-precision performance with options for top or bottom mounting. Whether used in CNC, industrial automation, or robotics, the systems steel construction and multiple size options ensure seamless integration and endurance.

Advanced Lubrication and Sealing

Integrated lubrication ports on the R1662 simplify upkeep by allowing grease or oil to be applied directly, maintaining consistent operation and reducing downtime. The double-sealed runner block effectively guards internal components against dust and debris, prolonging the lifespan of both rails and carriagesideal for varied and challenging industrial environments.

FAQs of Rexroth R1662:

Q: How is the Rexroth R1662 linear guide installed?

A: The R1662 can be mounted from either the top or bottom, depending on application demands and space constraints. Its compact height and flexible mounting options allow for seamless integration in automation, CNC machinery, or robotic systems.

Q: What are the available rail widths and precision classes for the R1662?

A: Standard rail widths for the R1662 are 15, 20, 25, 30, and 35 mm. Precision classes adhere to international ISO standards and include P, H, SP, and UP, allowing selection based on your tolerance and accuracy requirements.

Q: When should the integrated lubrication ports be used?

A: Lubrication intervals depend on operational load, speed, and environmental factors. The integrated ports simplify the processapply grease or oil as per the manufacturers recommendation to maintain optimal performance and extend component life.

Q: Where can Rexroth R1662 guides be sourced in India?

A: Rexroth R1662 linear guides are available through authorized distributors, importers, and suppliers across India. Dealers offer local support, product knowledge, and can assist with specification or custom length requirements.

Q: What is the process for ordering a custom rail length?

A: To request a custom length, consult your local Rexroth distributor or supplier. Provide the desired measurements and application information so the guide rails can be cut and supplied precisely to your requirement.

Q: What benefits does the double-sealed runner block design offer?

A: The double seal on the R1662 runner block ensures enhanced protection against dust, debris, and other contaminants. This feature reduces maintenance frequency and extends the service life of the linear rail system.

Q: How does interchangeability benefit system integration?

A: The R1662s compatibility with standard guide rails simplifies replacement and upgrades. Its interchangeable design reduces downtime during maintenance or retrofits, ensuring smooth workflow and long-term adaptability in evolving industrial applications.
