MINDMAN SOLENOID VALVE MVSC 220 4E1 DC 24 V

Get a Price/Quote

MOQ : 1 Piece

MINDMAN SOLENOID VALVE MVSC 220 4E1 DC 24 V Specification

Shape
Rectangular

Thread Type
PT (Pipe Thread)

Machine Type
Solenoid Valve for Pneumatic Systems

Method
Electromagnetic Actuation

Accuracy
High

Size
1/4 Inch (Port Size)

Coating
Anodized

Weight
Approx. 0.35 kg

Hardness
Standard

Type
5/2 Way Solenoid Valve

Material
Aluminum Alloy, Engineering Plastics

Tolerance
Standard

Surface
Smooth Finish

Use
Control of Pneumatic Actuators

Application
Industrial Automation, Pneumatic Systems

Usage & Applications
Directional Control of Compressed Air Flow

MINDMAN SOLENOID VALVE MVSC 220 4E1 DC 24 V Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Against Delivery (CAD)

Supply Ability
100 Pieces Per Day

Main Domestic Market
All India

About MINDMAN SOLENOID VALVE MVSC 220 4E1 DC 24 V

MINDMAN SOLENOID VALVE MVSC 220 4E1 DC 24 V

Body width	22mm
Bore No.	8A
Port size	PT 1/4
No. of port	3,5
No. of position	2,3
Medium	Air
Operating pressure range	2~7 kgf/cm2
Proof pressure	10 kgf/cm2
Flow	710~799Nl/min(5/3)
Effective orifice	16~18mm2
Response time	30ms-40ms
Ambient temperature	5-50 (No freezing)
Voltage	AC110V, 220V (50/60)Hz, DC24V
Power consumption	AC=6/4.9VA, DC=2.5W
Available voltage range	10%
Insulation class	F class
Weight	203g~421g
Model	MVSC-220 E1 24 V DC

Designed for Demanding Industrial Applications

The MVSC-220-4E1 is engineered to handle rigorous industrial automation and pneumatic system requirements. With quick response times of under 30 ms, this solenoid valve streamlines directional control for compressed air flow, making it an optimal choice for a wide array of industrial processes. Its robust construction suits demanding working conditions, contributing to reliable, long-lasting operation.

Versatile Installation and Mounting Options

This valve can be mounted base or body ported, allowing easy integration into new or existing pneumatic systems. Its compact, lightweight rectangular shape (around 0.35kg) ensures compatibility with limited spaces, while the individual exhaust type and push-button manual override enhance flexibility and safety during installation and maintenance.

FAQs of MINDMAN SOLENOID VALVE MVSC 220 4E1 DC 24 V:

Q: How does the MINDMAN MVSC-220-4E1 solenoid valve operate within a pneumatic system?

A: The valve utilizes electromagnetic actuation to rapidly control compressed air flow, directing it through its five ports and two positions. This enables precise switching in pneumatic actuators, essential for reliable and accurate automation processes.

Q: What are the key benefits of using this solenoid valve in industrial automation?

A: Its fast response time (under 30 ms), high reliability, IP65 protection class, and low power consumption (1.5W) make it highly suitable for critical automation tasks. The robust aluminum and engineering plastic construction ensure durability in demanding settings.

Q: When should this solenoid valve be selected over other types?

A: Choose the MVSC-220-4E1 when you require a 5/2 way valve for controlling double-acting pneumatic cylinders, especially for applications demanding quick response, compact design, high accuracy, and dependable sealing provided by NBR (Nitrile Rubber).

Q: Where can the MVSC-220-4E1 be used?

A: The valve finds use in a variety of environments such as manufacturing plants, assembly lines, and automated industrial equipment across India, particularly for pneumatic actuator control and compressed air flow direction.

Q: What is the process for mounting and connecting this valve?

A: The MVSC-220-4E1 supports both base and body ported mounting. Electrical connection is achieved via a DIN terminal, and PT thread ensures secure air line attachment. A manual push button override facilitates safe setup and maintenance.

Q: How does the IP65 protection rating benefit users?

A: IP65 protection ensures the valve is dust-tight and safeguarded against jets of water from any direction, making it suitable for harsh industrial environments without compromising performance.
