MINDMAN MCMB series (Standard with Magnet)

Get a Price/Quote

MOQ : 1 Piece

MINDMAN MCMB series (Standard with Magnet) Specification

Weight
Varies by model (e.g., approx. 0.3 kg for 32 mm bore x 50 mm stroke)

Shape
Round

Hardness
High

Thread Type
Metric

Machine Type
Pneumatic Cylinder

Method
Pneumatic actuation

Load Capacity
Depends on diameter and pressure (e.g., up to 785 N at 0.5 MPa for 50 mm bore)

Coating
Anodized coating

Size
Bore size range: 16 mm to 100 mm

Accuracy
High repeatability within cylinder stroke

Type
Double Acting Cylinder

Material
Aluminum alloy

Tolerance
0.2 mm

Surface
Anodized

Use
Compressed air drive

Application
Industrial automation, Pneumatic systems

Usage & Applications
Linear motion control in machinery

Piston Seal
NBR (Standard), FKM (Optional)

Operating Pressure Range
0.1~1.0 MPa

Cushion Type
Rubber Cushion at Both Ends

Mounting Style
Basic, LB, FA, FB, CA, CB

Rod End Thread
Male or Female

Stroke Length
Up to 500 mm (depends on bore size)

Maximum Speed
500 mm/s

Ambient Temperature
-20°C to +80°C

Port Size
M5x0.8 (for 16/20 mm), Rc1/8 (for 25/32/40 mm)

Magnet Availability
Standard (for Sensor Mounting)

Magnetic Sensor
Compatible (Optional)

About MINDMAN MCMB series (Standard with Magnet)

Discover the MINDMAN MCMB Series (Standard with Magnet): a brilliant, double-acting pneumatic cylinder that offers high accuracy, sterling reliability, and unbeatable price. Designed with an anodized aluminum round body, its both lightweight and highly durable. Enjoy fast linear motion up to 500 mm/s and the versatility of multiple mounting styles. With ravishing pressure capabilities (0.1~1.0 MPa), a wide operating temperature, excellent load capacity, and exclusive compatibility with magnetic sensors, its engineered for robust industrial automation. Limited stocksecure this top-tier solution for your machinery today!

Distinguished Features & Industrial Applications

The MINDMAN MCMB Series stands out for its extensive featuresrobust anodized coating, high hardness, impressive tolerance, and fast actuation. Compatible with magnetic sensors and various mounting styles, it integrates seamlessly into industrial applications. Perfect for pneumatic systems and linear motion control in machinery, it shines in environments needing reliability and smooth operation. Its commercial uses span across factory automation, assembly lines, and precision engineering, providing long-lasting performance and flexibility.

Sample Policy, Supply Ability & Certifications Overview

The MCMB Series offers a transparent sampling policy for qualified buyers to evaluate its market value before bulk purchase orders. With reliable supply ability backed by global distributor and importer networks, timely fulfillment is ensured, adding to market valuation. Only certified products are delivered, meeting industrial standards and boosting client confidence. Contact us directly for sample requests, order placement, and details on compliance certifications for your specific application.

FAQs of MINDMAN MCMB series (Standard with Magnet):

Q: How does the MINDMAN MCMB Series achieve high accuracy in operation?

A: The MCMB Series achieves high accuracy through precise manufacturing tolerances (0.2 mm) and advanced piston seal materials, ensuring consistent and repeatable linear motion within the cylinders stroke.

Q: What types of commercial and industrial environments can use this pneumatic cylinder?

A: It is designed for a wide range of industrial automation settings, including pneumatic systems, factory machinery, assembly lines, and processes requiring reliable linear motion control.

Q: When should I consider using an optional magnetic sensor with this cylinder?

A: An optional magnetic sensor is recommended when precise piston position feedback is needed, such as in automated applications where monitoring cylinder stroke enhances operation safety and process control.

Q: Where can the MCMB Series be mounted, and what styles are available?

A: This cylinder supports multiple mounting styles, including Basic, LB, FA, FB, CA, CB options, making it versatile for various installation requirements in machinery and automated systems.

Q: What is the process for ordering samples or requesting certification documents?

A: You can request product samples or certification documentation by contacting the distributor or supplier directly. Provide a valid purchase order and specify your industrial requirements for tailored assistance.

Q: How does the MCMB Series benefit applications in terms of durability and maintenance?

A: Thanks to its anodized surface and high-quality materials, the MCMB Series offers superior durability, corrosion resistance, and reduced maintenance downtime, contributing to long-term operational efficiency.
