MINDMAN MAL series(AIR UNIT)

1000.00 - 10000.00 INR

Get a Price/Quote

Product Details:

Accuracy High filtration precision (up to 5 micron particle filtration)
Thread Type BSPT/NPT threads
Hardness High-strength aluminum construction
Method Modular assembly with individual or combined usage
Machine Type Pneumatic circuit air line unit
Shape Compact modular design
Size Available in multiple port sizes (1/8, 1/4, 3/8, 1/2 inch)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

MINDMAN MAL series(AIR UNIT) Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 1000.00 - 10000.00 INR

MINDMAN MAL series(AIR UNIT) Product Specifications

Material Aluminum alloy body
Accuracy High filtration precision (up to 5 micron particle filtration)
Hardness High-strength aluminum construction
Thread Type BSPT/NPT threads
Method Modular assembly with individual or combined usage
Surface Anodized finish for corrosion resistance
Usage & Applications Industrial automation, manufacturing, assembly lines
Type Air preparation unit (FRL: Filter, Regulator, Lubricator)
Use Air filtration, regulation, and lubrication in pneumatic systems
Load Capacity Maximum pressure up to 1.0 MPa (10 bar)
CNC Yes
Weight Varies by model (approx. 400g to 1800g)
Machine Type Pneumatic circuit air line unit
Tolerance Standard ISO Tolerance
Shape Compact modular design
Size Available in multiple port sizes (1/8, 1/4, 3/8, 1/2 inch)
Coating Anodized and powder coated
Application For pneumatic machinery and automation systems

Product Description

Experience the exclusive performance of the illustrious MINDMAN MAL Series (AIR UNIT) a masterful integration of filtration, regulation, and lubrication for pneumatic systems. Meticulously crafted from high-strength aluminum alloy with a rarefied anodized finish, this compact modular unit ensures high-precision air preparation. Its replaceable filter offers up to 5 micron particle filtration, while oil, water, and particulate contaminants are effortlessly managed. Explore multiple port sizes and versatile mounting options. Add to Cart today and elevate your automation with this CNC-compatible, ISO-compliant air preparation solution.

Competitive Advantages & Surface Applications

The MINDMAN MAL Series (AIR UNIT) boasts a rare blend of durability and adaptability, constructed from robust anodized and powder-coated aluminum alloy. Designed for seamless integration, its masterful build resists oil, water, and particulate contamination while providing high filtration precision. Compatible with ISO 8573-1 standards and modular installation, it excels in industrial automation and CNC assembly linesdemonstrating superior material features for exacting applications on manufacturing floors, automated lines, and assembly machinery.

Sample Availability & Delivery Information

Customers may request samples of the exclusive MINDMAN MAL Series (AIR UNIT) to assess its application suitability. Secure shipping ensures prompt and safe delivery, with standard shipment typically dispatched within 7 to 15 working days, depending on order volume. Sale price and payment terms can be tailored to your procurement needs, with flexible transaction options available. Experience a seamless purchasing processexplore, inquire, and benefit from streamlined logistics and responsive support.

MODEL NO.

MAL200-6A.8A

MAL200L-6A.8A

MAL300-8A.10A

MAL300L-8A.10A

MAL302-8A.10A.15A

MAL302-8A.10A.15A-N

MAL302-8A.10A.15A-M

MAL302-8A.10A.15A-M-B

MAL400-8A.10A.15A

MAL401-8A.10A.15A

MAL402-10A.15A

MAL402-20A

MAL403-8A.10A.15A

MAL501-20A.25A

501 NYLON BOWL(EACH)

501 METAL BOWL(EACH)

MAL900-40A

FAQs of MINDMAN MAL series(AIR UNIT):

Q: How is the MINDMAN MAL Series (AIR UNIT) used in industrial automation?

A: The MAL Series is installed in pneumatic circuits to filter, regulate, and lubricate compressed air, ensuring optimal machinery performance and longevity in automated manufacturing and assembly environments.

Q: What materials make up the MAL Series air units, and how do they enhance durability?

A: Each unit features a high-strength aluminum alloy body, anodized and powder coated for corrosion resistance, complemented by NBR seals and a polycarbonate bowl with a protective cover, delivering both robustness and chemical resistance.

Q: Where can the MINDMAN MAL Series be mounted within a pneumatic system?

A: The MAL Series offers bracket and panel mounting options, allowing for flexible installation directly on machine frames, control panels, or distribution manifolds in a variety of industrial setups.

Q: What is the process for selecting the correct model from the MAL Series table?

A: Determine application requirements such as required flow rate, port size, drain type, and system pressure, then match these criteria to the available MAL model numbers listed in the provided table.

Q: When and how should the filter element in the MAL Series be replaced?

A: Replace the filter element according to maintenance schedules or when a significant pressure drop is observed. The design offers straightforward removal and installation for minimal downtime.

Q: What benefits do the manual and automatic drain options provide?

A: Manual drains allow user-controlled condensate removal, while automatic drains facilitate unattended water discharge, reducing maintenance and enhancing system reliability.
