INA Linear Guideways

1000.00 - 10000.00 INR/Piece

Get a Price/Quote

Product Details:

Weight Depends on Rail Length and Size, typically 0.512 kg/m
Thickness Guideway Height 18 mm to 48 mm (Model Specific)
Material High-Quality Alloy Steel
Ball Bearing Type Precision Ground, Four-Point Contact Ball Bearings
Roller Bearing Type Cylindrical Roller Bearings (For Selected Series)
Bushes Type Linear Plain Bushings
Structure Double-Row Linear Guideway with Integral Rails and Carriages
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

INA Linear Guideways Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 1000.00 - 10000.00 INR/Piece

INA Linear Guideways Product Specifications

Bore Size 15 mm to 55 mm (varies by model)
Outside Diameter Varies by Linear Guide Model
Seals Type Double Lip Contact Seals on Both Sides
Limiting Speed Up to 5 m/s
Load Capacity Dynamic Load Rating up to 112 kN (Depending on Series)
Material High-Quality Alloy Steel
Inner Diameter 15 mm to 55 mm (Model Dependent)
Bushes Type Linear Plain Bushings
Ball Bearing Type Precision Ground, Four-Point Contact Ball Bearings
Number Of Rows 2
Structure Double-Row Linear Guideway with Integral Rails and Carriages
Thickness Guideway Height 18 mm to 48 mm (Model Specific)
Weight Depends on Rail Length and Size, typically 0.512 kg/m
Roller Bearing Type Cylindrical Roller Bearings (For Selected Series)

INA Linear Guideways Trade Information

Supply Ability 1000 Piece Per Month
Delivery Time 1 Days

Product Description

INA Linear Guideways are highly recommended for demanding industrial applications, offering first-rate precision and top-drawer durability. With a wide rail length rangefrom 100 mm up to over 4000 mmand both top and bottom mounting types, these hot deal guideways cater to customized installations. Carriage options include standard, long, and wide, matched with first-string preload classes for optimized performance. Available in normal, high, or precision accuracy grades, the corrosion-resistant coatings and factory pre-lubrication reduce maintenance. Interchangeable carriages and rails and advanced seals ensure seamless operation, making them a superior choice for CNC, automation, robotics, and packaging industries.

Versatile Applications and Advanced Features of INA Linear Guideways

INA Linear Guideways deliver reliable performance in CNC machinery, robotics, automation, packaging and printing. These double-row linear guideways support dynamic loads up to 112 kN and boast maintenance-free operation with factory pre-lubrication. Thanks to precision-ground ball bearings and high-quality alloy steel construction, they stand up to intensive use across industrial machinery. Corrosion-resistant coatings, versatile mounting options, and interchangeability further enhance usage in diverse manufacturing, engineering, and automation sectors.

Supply Ability, Main Export Markets and Certifications of INA Linear Guideways

INA Linear Guideways are available for express shipping through authorized distributors, importers, and suppliers in Germany. With large supply ability, orders are handed over promptly for global delivery. Certifications such as ISO standards assure quality and reliability, giving added charge to your production efficiency. Main export markets include Europe, Asia, and North America. Buyers can expect swift logistics and compliance with international machine tool regulations, making every transaction smooth and dependable.

FAQs of INA Linear Guideways:

Q: How do INA Linear Guideways ensure precision and reliability in industrial applications?

A: INA Linear Guideways are manufactured from high-quality alloy steel and utilize precision-ground four-point contact ball bearings or cylindrical roller bearings. Their advanced preload and accuracy grades allow for stable, accurate movements, which is critical in CNC machinery, robotics, and automated processes.

Q: What is the process for mounting INA Linear Guideways and selecting appropriate carriage types?

A: Mounting can be top or bottom, depending on your machine requirements. Customers can select from standard, long, or wide carriages based on load distribution and space constraints. Carriages and rails within the same size range are interchangeable for flexible installation.

Q: Where are INA Linear Guideways typically used?

A: These guideways are widely used in CNC machines, industrial automation, robotics, packaging, and printing equipment, owing to their robust construction, reduced maintenance, and excellent load capacity.

Q: What are the benefits of factory pre-lubrication and maintenance-free options for INA Linear Guideways?

A: Factory pre-lubrication ensures smooth operation from installation and minimizes wear. Maintenance-free options reduce downtime, delivering long-term operational savings and decreasing manual servicing needs.

Q: When should you choose corrosion-resistant coatings on INA Linear Guideways?

A: Corrosion-resistant black oxide or nickel plating are advisable for applications operating in humid, chemically-aggressive, or outdoor environments, as they protect the guideways and extend service life.

Q: How quickly can INA Linear Guideways be supplied and shipped internationally?

A: INA Linear Guideways are available for express shipping through authorized channels, ensuring swift processing and international dispatch. Lead times may vary based on order size and customization but are optimized for rapid delivery to major global markets.
