Single Axis Robot
KK Series

Features

Caption:
An integrated system
 Easy installation and maintenance
 Compact and lightweight
 High accuracy
 High stiffness
Complete selection of accessories for
most applications.
The KK Single Axis Robot features a slider actuated by a motor-driven ballscrew and guided by a linear guideway
with a U-shape rail. The slider acts as the ballscrew’s nut and the guideway’s block.
Example: KK6010P-400A1-F1CS0
MODEL
KK40
KK50
KK60
KK86
KK100
KK130

Single Axis Robot
KA Series
*Belt driven KA is preferred to be used in horizontal applications. Maximum linear velocity of 1800 mm/sec.
Features
1. Complete selection of modules and accessories for most applications.
Driven Type???ballscrew, toothed belt
AC motor output???30W???750W servo motor or step motor
Motor connection type (depends on available space)???direct, bottom, internal, left, right
Max stroke???100mm???3000mm
Maximum load???max of 221kg horizontally and max of 61kg vertically.
2. Easy transformation into a multi-axis robot.

Specification
The KA series designation is represented as the following:
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10)
Model Lead Precision
Grade
Effective
Stroke
Load
Type
Motor
Flange
Aluminum
Cover
Limit
Switch Motor Installation

MODEL
KA100
KA136
KA170

EXAMPLE:KA100 -20 P -500 A F0 U S1 M V

Single Axis Robot
KS Series
Features
 Reasonable price
 Use in Clean room
 Stainless covers
 Already installed AC servo motor (optional)
 High repeatability ±0.02mm
 Dust proof
 Support different strokes

Applications

 FPD industry
 Semiconductor
 Medical applications
 FPD glass transfer
 Inspection & testing equipment

EXAMPLE:KS05 -04 -0200 -C -M1 D B -S1 -5 -F1

KS SERIES
MODEL
KS05-04
KS10-10
