Hiwin Rolled Ball Screws

Get a Price/Quote

MOQ : 1 Piece

Hiwin Rolled Ball Screws Specification

Weight
2.1 kg

Thickness
15 mm

Material
Alloy Steel

Ball Bearing Type
Single Row

Roller Bearing Type
Cylindrical

Bushes Type
Flange Type

Structure
Axial

Seals Type
Double Sealed

Number Of Rows
1

Bore Size
16 mm

Outside Diameter
40 mm

Limiting Speed
3600 rpm

Load Capacity
2140 kgf

Inner Diameter
16 mm

Shaft Surface Treatment
Ground, Hardened

Lubrication
Grease Lubricated

Application
CNC machines, Automation Equipment

Noise Level
Low

Length
1000 mm

Lead
5 mm

Backlash
0.05 mm

Type
Rolled Ball Screw

Precision Grade
C7 standard

Mounting Method
End Supported

Corrosion Resistance
High

Dynamic Load Rating
2500 N

Hiwin Rolled Ball Screws Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
1 Days

About Hiwin Rolled Ball Screws

Hiwin Rolled Ball Screws

Item Code: Ball-Screws

Hiwin Rolled Ball Screws

Hiwin Ball Screws
Hiwin Rolled Ball Screws

Hiwin Rolled Ball Screws are made by the rolling process of the screw spindle instead of the grinding process. Rolled ball screws not only have the benefit of low friction and smooth running for the linear feed system compared with traditional screws, but also can be supplied by quick stock delivery and lower production price.

Engineered for Precision and Durability

Our Hiwin Rolled Ball Screws (C7 grade) combine ground, hardened alloy steel with double-sealed construction to ensure long-lasting performance. With minimal backlash and precise movement, they excel in CNC machines and advanced automation systems, delivering repeatable accuracy crucial for industrial operations. The corrosion-resistant finish and efficient grease lubrication further enhance their reliability in challenging environments.

Ideal for High-Demand Industrial Applications

Designed with a dynamic load rating of 2500 N and a high load capacity of 2140 kgf, these ball screws are perfect for heavy-duty projects. Their end-supported mounting method and single-row ball bearing structure make them suitable for sustained use in CNC machinery and automated production lines. Low noise levels ensure quiet operation, making them ideal for both small workshops and large-scale factories.

FAQs of Hiwin Rolled Ball Screws:

Q: How are Hiwin Rolled Ball Screws installed in CNC and automation equipment?

A: Hiwin Rolled Ball Screws (Type: End Supported) are typically mounted at both ends to ensure stability and precise alignment within CNC machines or automation setups. Installation involves aligning the shaft with the support housings, securing them with appropriate mounting hardware, and ensuring correct preload and lubrication for optimal performance.

Q: What benefits does the C7 precision grade offer for industrial applications?

A: The C7 standard precision grade guarantees consistent accuracy and minimal backlash (0.05 mm), making these ball screws ideal for tasks requiring reliable linear motion. This level of precision is particularly advantageous for CNC machining and automated processes where repeatability and accuracy are essential.

Q: When should I lubricate Hiwin Rolled Ball Screws, and which lubricant is recommended?

A: Regular lubrication is essential for maintaining smooth performance. It is recommended to use grease as specified, and reapply according to the machines workload and environmenttypically every 3 to 6 months. Proper lubrication minimizes wear, reduces noise, and extends the lifespan of the ball screw system.

Q: Where can I source Hiwin Rolled Ball Screws in India?

A: We are an official distributor, importer, and supplier of Hiwin Rolled Ball Screws in India. Our network ensures quick delivery and reliable after-sales support, catering to a wide range of industrial and automation needs nationwide.

Q: What process is used to manufacture these ball screws for enhanced durability?

A: Hiwin Rolled Ball Screws are produced using a rolling technique for the threads, followed by grinding and hardening of the shaft surface. This process enhances surface smoothness and ensures superior durability and corrosion resistance, making the screws suitable for demanding industrial environments.

Q: How does the low noise level benefit machine operation?

A: Low noise operation reduces overall sound levels in workshops or factories, leading to a more comfortable and safer working environment. It also helps in maintaining machine stability by minimizing vibration-related disturbances during high-speed or continuous operation.
