Hiwin HGW Series 15 20 25 35 45 55 65-Ca-ha-cc-hc-zoc-zah

1000.00 - 10000.00 INR/Piece

Get a Price/Quote

Product Details:

Thickness Standard as per model
Weight Depends on specification (approx. 0.4 kg up to 14 kg)
Material Bearing Steel / Stainless Steel
Ball Bearing Type Linear Guideways
Seals Type Double Sealed
Number Of Rows 4
Bore Size 15 mm, 20 mm, 25 mm, 35 mm, 45 mm, 55 mm, 65 mm
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Hiwin HGW Series 15 20 25 35 45 55 65-Ca-ha-cc-hc-zoc-zah Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 1000.00 - 10000.00 INR/Piece

Hiwin HGW Series 15 20 25 35 45 55 65-Ca-ha-cc-hc-zoc-zah Product Specifications

Limiting Speed Up to 70 m/min (depends on model)
Material Bearing Steel / Stainless Steel
Bore Size 15 mm, 20 mm, 25 mm, 35 mm, 45 mm, 55 mm, 65 mm
Weight Depends on specification (approx. 0.4 kg up to 14 kg)
Number Of Rows 4
Outside Diameter Varies as per model
Seals Type Double Sealed
Ball Bearing Type Linear Guideways
Inner Diameter Varies as per model (e.g., 15 mm to 65 mm)
Thickness Standard as per model
Load Capacity High LoadVaries by size and mounting type

Hiwin HGW Series 15 20 25 35 45 55 65-Ca-ha-cc-hc-zoc-zah Trade Information

Supply Ability 1000 Piece Per Month
Delivery Time 1 Days

Product Description

Hiwin HGW Series 15 20 25 35 45 55 65-Ca-ha-cc-hc-zoc-zah

Hiwin Flange Type HGW Series

HIWIN HGW Series Flange type 15 20 25 35 45 55 65 CC-HC
HGW

Four row for super heavy load

Applications:

Machining centers
Machine tools
Heavy cutting machines
Grinding machines
Injection molding machine
Automatic equipment
High speed transfer device

Superior Versatility Across Applications

The HGW Series accommodates a wide range of industrial uses, including CNC machinery and automation systems. With multiple block types and mounting options (top or bottom), users can customize their setup for optimal performance and flexibility, making it suitable for both standard and specialized installations.

Precision Engineering and Robust Construction

Constructed from high-grade bearing steel or stainless steel, these linear guideways are designed for high-load bearing while maintaining exceptional accuracy. The selection of five accuracy classes ensures that operations demanding the highest levels of precision are effectively supported.

Long-Lasting Performance and Easy Maintenance

Featuring integrated grease fittings and double seals, the HGW Series is engineered for durability and minimal maintenance. Anti-corrosion options are available by request, prolonging the lifespan even in challenging industrial environments.

FAQs of Hiwin HGW Series 15 20 25 35 45 55 65-Ca-ha-cc-hc-zoc-zah:

Q: How do I select the right HGW Series model and block type for my application?

A: Choosing the appropriate HGW Series model and block type depends on your applications load, speed, precision requirements, and mounting constraints. Consider the rail width (ranging from 15 mm to 65 mm), block type (such as CA, HA, CC, HC, ZOC, or ZAH), and preload class (low, medium, or high). Consulting application data and load charts is recommended for optimal selection.

Q: What are the main benefits of using Hiwin HGW Series linear guideways in CNC machines?

A: Hiwin HGW Series linear guideways provide high load capacities, superior precision, and low friction, which translates to improved machining accuracy and system longevity in CNC applications. Integrated lubricating fittings and double-sealed construction also ensure reliable operation and reduced maintenance demands.

Q: When should I request anti-corrosion treatment for my Hiwin HGW linear guideways?

A: Anti-corrosion treatment is advisable for installations exposed to humid, wet, or chemically aggressive environments. If your machinery operates in such conditions or requires extended service intervals, specify anti-corrosion treatment when ordering or consulting with your distributor in India.

Q: Where can these linear guideways be installed and mounted?

A: The HGW Series linear guideways can be mounted from the top or bottom, offering adaptability for diverse equipment layouts. This versatility allows installation in a wide range of machinery, including automation lines and precision equipment, depending on space and configuration needs.

Q: What is the maintenance process for HGW Series linear guideways?

A: Regularly lubricate via the integrated grease fitting and inspect the double seals to maintain performance. Periodic checking and cleaning help extend the service life, and if anti-corrosion treatment was selected, less frequent maintenance may be necessary, depending on the application environment.

Q: How does the accuracy classification affect HGW Series guide performance?

A: Accuracy classes (C, H, P, SP, UP) determine the guideways alignment, smoothness, and allowable deviation. For applications such as high-precision CNC and inspection systems, higher accuracy classes (P, SP, UP) are preferred. Standard industrial uses may opt for classes C or H.
