HIWIN HGH 65 HA

HIWIN HGH 65 HA
HIWIN HGH 65 HA
Product Code : 701
Brand Name : HIWIN
Product Description

Series/

size   dimensions [mm]

W B B1 C L1 L K1 K2 G M × l T H2 H3

HGH15CA 28 4,3 9,5 34 26,0 4,0 26 39,4 61,4 10,00 4,85 5,3 M4 × 5 6,0 7,95 7,7 11380 16970 0,18

QHH15CA 28 4,0 9,5 34 26,0 4,0 26 39,4 61,4 10,00 5,00 5,3 M4 × 5 6,0 7,95 8,2 13880 14360 0,18

HGH20CA

30 4,6 12,0 44 32,0 6,0

36 50,5 77,5 12,25

6,00 12,0 M5 × 6 8,0 6,00 6,0

17750 27760 0,30

HGH20HA 50 65,2 92,2 12,60 21180 35900 0,39

QHH20CA

30 4,6 12,0 44 32,0 6,0

36 50,5 76,7 11,75

6,00 12,0 M5 × 6 8,0 6,00 6,0

23080 25630 0,29

QHH20HA 50 65,2 91,4 12,10 27530 31670 0,38

HGH25CA

40 5,5 12,5 48 35,0 6,5

35 58,0 84,0 15,70

6,00 12,0 M6 × 8 8,0 10,00 9,0

26480 36490 0,51

HGH25HA 50 78,6 104,6 18,50 32750 49440 0,69

QHH25CA

40 5,5 12,5 48 35,0 6,5

35 58,0 83,4 15,70

6,00 12,0 M6 × 8 8,0 10,00 9,0

31780 33680 0,50

QHH25HA 50 78,6 104,0 18,50 39300 43620 0,68

HGH30CA

45 6,0 16,0 60 40,0 10,0

40 70,0 97,4 20,25

6,00 12,0 M8 × 10 8,5 9,50 13,8

38740 52190 0,88

HGH30HA 60 93,0 120,4 21,75 47270 69160 1,16

QHH30CA

45 6,0 16,0 60 40,0 10,0

40 70,0 97,4 19,50

6,25 12,0 M8 × 10 8,5 9,50 9,0

46490 48170 0,87

QHH30HA 60 93,0 120,4 21,75 56720 65090 1,15

HGH35CA

55 7,5 18,0 70 50,0 10,0

50 80,0 112,4 20,60

7,00 12,0 M8 × 12 10,2 16,00 19,6

49520 69160 1,45

HGH35HA 72 105,8 138,2 22,50 60210 91630 1,92

QHH35CA

55 7,5 18,0 70 50,0 10,0

50 80,0 113,6 19,00

7,50 12,0 M8 × 12 10,2 15,50 13,5

60520 63840 1,44

QHH35HA 72 105,8 139,4 20,90 73590 86240 1,90

HGH45CA

70 9,5 20,5 86 60,0 13,0

60 97,0 139,4 23,00

10,00 12,9 M10 × 17 16,0 18,50 30,5

77570 102710 2,73

HGH45HA 80 128,8 171,2 28,90 94540 136460 3,61

QHH45CA

70 9,2 20,5 86 60,0 13,0

60 97,0 139,4 23,00

10,00 12,9 M10 × 17 16,0 18,50 20,0

89210 94810 2,72

QHH45HA 80 128,8 171,2 29,09 108720 128430 3,59

HGH55CA

80 13,0 23,5 100 75,0 12,5

75 117,7 166,7 27,35

11,00 12,9 M12 × 18 17,5 22,00 29,0

114440 148330 4,17

HGH55HA 95 155,8 204,8 36,40 139350 196200 5,49

HGH65CA

90 15,0 31,5 126 76,0 25,0

70 144,2 200,2 43,10

14,00 12,9 M16 × 20 25,0 15,00 15,0

163630 215330 7,00

HGH65HA 120 203,6 259,6 47,80 208360 303130 9,82
