Twin-guide Cylinder Model: MCGA

Get a Price/Quote

MOQ : 1 Piece

Twin-guide Cylinder Model: MCGA Specification

Size
Bore Size: 16mm, 20mm, 25mm (others on request)

Machine Type
Pneumatic Cylinder/Actuator

Load Capacity
Up to 20 kg (depending on model)

Accuracy
High Precision Guidance

Weight
Varies with stroke and bore size

Coating
Hard Anodized

Shape
Rectangular

Method
Air-driven (Pneumatic)

Thread Type
Metric

Hardness
Approx. 80 HRA

Type
Twin-guide Cylinder

Material
Aluminum Alloy

Tolerance
0.01 mm

Surface
Anodized Finish

Use
Linear Motion Applications

Application
Packaging, Assembly lines, Automation

Usage & Applications
Guided Cylinder for Anti-rotative and Lifting Operations

About Twin-guide Cylinder Model: MCGA

Twin-guide Cylinder Model: MCGA

Tube I.D. 20, 32, 40, 50, 63, 80 (mm). Strong cylinder suitable for heavy load,for stopping work carriers of various sizes at a fixed position, and for stacking many work carriers, etc.

Features

Strong cylinder capable of high loads, used extensively for stopping work carriers in both the vertical and horizontal position.
Large diameter guide rods enable cylinder to take high off-set loads.
Can be used as 90 degree pusher on large conveyor systems.
Magnetic as standard.

Specifications :

Acting type	Double acting
Tube I.D. (mm)	20,32,40,50,63,80
Port size	PT 1/8,PT 1/4,PT 3/8
Medium	Air
Operating pressure range	1~9.9 kgf/cm2
Proof pressure	15 kgf/cm2
Ambient temperature	5~ 60 (No freezing)
Lubrication	Not required
Cushion	With rubber cushion pad
Sensor switch	RCB

Superior Precision and Reliability

Engineered for automation, the MCGA twin-guide cylinder delivers consistent high-precision motion, courtesy of its 0.03 mm repeating accuracy and 0.01 mm tolerance. Robust aluminum construction and stainless steel guide rods ensure stability even under demanding conditions, enhancing reliability in linear motion tasks.

Versatile Mounting and Customization

This cylinder offers flexible mounting through through-hole or tapped options and accommodates port sizes M5 and PT1/8". Tailor the stroke length (20mm to 100mm) and choose from various bore sizes (16mm, 20mm, 25mm, others upon request) for integration into diverse configurations, making it suitable for complex industrial needs.

Ideal for Industrial Automation

The MCGA cylinder is optimized for automation in packaging lines, assembly operations, and lifting applications. Its hard anodized surface, NBR sealing, and rubber bumper cushioning guarantee durability, smooth operation, and minimized maintenancemaximizing uptime and machinery longevity in industrial workflows.

FAQs of Twin-guide Cylinder Model: MCGA:

Q: How can the stroke length of the Twin-guide Cylinder MCGA be customized for different applications?

A: The MCGA model supports stroke lengths between 20mm and 100mm. Custom stroke configurations allow you to select the exact length needed for your specific linear motion application. Consult the supplier or distributor to order a cylinder with custom stroke specifications.

Q: What mounting types are available for installation of the MCGA Twin-guide Cylinder?

A: This model offers both through hole and tapped mounting options. These versatile mounting types simplify integration into various machine frames and layouts, allowing secure installation in multiple industrial environments.

Q: When is it recommended to use a twin-guide cylinder like the MCGA in manufacturing operations?

A: A twin-guide cylinder is recommended when you require anti-rotative movement, precise linear guidance, and stable lifting functions. It is particularly suitable in packaging, automated assembly lines, and any task where accuracy and repeatability are critical.

Q: Where can the MCGA Twin-guide Cylinder be sourced in India?

A: This cylinder model is available through authorized distributors, suppliers, and importers across India. You can contact local pneumatic solutions providers or reach out to the manufacturer for purchasing options tailored to your region.

Q: What are the key benefits of using a pneumatic twin-guide cylinder with a hard anodized finish and stainless steel guide rods?

A: The hard anodized finish increases corrosion resistance and durability, while stainless steel guide rods provide rigidity and smooth guidance. Together, they ensure longer service life, reliability in harsh environments, and consistent performance under dynamic loads.

Q: How does the MCGA model ensure high precision and stability during operation?

A: This cylinder offers high precision due to its repeating accuracy of 0.03 mm and tight tolerance of 0.01 mm. Its robust rectangular aluminum structure and twin stainless steel guide rods maintain alignment and anti-rotative control, even at high speeds and varying loads.

Q: What sealing and cushioning options does the MCGA Twin-guide Cylinder provide for optimal performance?

A: The MCGA cylinder uses standard NBR sealing for efficient pneumatic performance and resilience. Additionally, it features a rubber bumper cushion, reducing impact during end-of-stroke and prolonging the actuators operational life.
