TPI Ball Screw Support Bearings BS 20 tac 47

Get a Price/Quote

MOQ : 1 Piece

TPI Ball Screw Support Bearings BS 20 tac 47 Specification

Lubrication Type
Grease/Oil

Thickness
15 mm

Precision Rating
P4 (High Precision)

Inside Diameter
20 mm

Cage Material
Steel

Retainer
Non-contact

Bearing Type
Ball Screw Support Bearing

Material
High Carbon Chromium Steel

Structure
Angular Contact Ball Bearing

Seals Type
Open

Number Of Rows
Single Row

Bore Size
20 mm

Outside Diameter
47 mm

Limiting Speed
11,000 rpm (Grease), 16,000 rpm (Oil)

Load Capacity
Dynamic 28.5 kN / Static 25 kN

Contact Angle
60°

Standard
ISO/JIS

Temperature Range
-40°C to +120°C

Application
CNC machinery, Ball screw support, Machine tools

Inner Ring Type
Extended

Finish
Precision ground

Shape
Cylindrical

Mounting
Universal matching, modular mountable

About TPI Ball Screw Support Bearings BS 20 tac 47

Discover the top-rated TPI Ball Screw Support Bearings BS 20 tac 47, engineered for first-string performance in CNC machinery, ball screw supports, and precision machine tools. This hot deal features a polished, precision-ground cylindrical shape with a robust extended inner ring, precision P4 rating, and crafted from excellent high carbon chromium steel. Enjoy modular mountability, open seal design, and universal match fitting. With a 60 contact angle and dynamic load capacity of 28.5 kN, this is your last chance to secure reliable, high-speed support compliant with ISO/JIS standards. Distributors, importers, and suppliers across India trust TPI for enduring value.

Competitive Advantages & Distinct Features

TPI Ball Screw Support Bearings BS 20 tac 47 offer consistent performance for demanding CNC machinery, machine tools, and ball screw support systems. Their competitive advantage lies in high precision P4 ratings, modular versatility, and a superior dynamic load capacity of 28.5 kN. These bearings are used extensively for accurate positioning and efficient mechanical motion. Precision-ground finishes, universal mounting, and robust temperature tolerance ensure reliability, making them the preferred choice in high-value industrial applications.

FOB Port, Certifications & Logistics

TPI Ball Screw Support Bearings BS 20 tac 47 hold significant market value due to their excellent certifications and compliance with global ISO/JIS standards. Transportation is efficiently managed via major Indian FOB ports, ensuring prompt delivery and premium packaging to prevent transit damage. Our sample policy supports inspection and confidence before bulk purchase. Each bearing is shipped to maximize protection, enhancing both the suppliers credibility and customer satisfaction throughout the logistics chain.

FAQs of TPI Ball Screw Support Bearings BS 20 tac 47:

Q: How are TPI Ball Screw Support Bearings BS 20 tac 47 commonly used in industrial applications?

A: They are primarily used in CNC machinery, ball screw supports, and precision machine tools for providing high precision and stable mechanical motion.

Q: What certifications do the TPI BS 20 tac 47 bearings comply with?

A: These bearings are manufactured according to ISO and JIS standards, ensuring internationally recognized quality and reliability.

Q: Where can I secure genuine TPI Ball Screw Support Bearings BS 20 tac 47 in India?

A: Authorized distributors, importers, and suppliers across India provide genuine TPI BS 20 tac 47 bearings backed by full support and warranty.

Q: What is the benefit of a 60 contact angle in these bearings?

A: A 60 contact angle enables the bearing to support higher axial loads, crucial for precise performance in ball screw support applications.

Q: How is the packaging quality maintained during transportation?

A: Bearings are packaged using premium materials to ensure protection from damage, preserving market value and functioning throughout transportation.

Q: When is it advisable to select open seal type bearings like the BS 20 tac 47?

A: Open seal type bearings are ideal when frequent maintenance or easy lubrication is needed, and contamination risk is low in the application environment.
