Stopper Cylinder Model: MSBS

Get a Price/Quote

MOQ : 1 Piece

Stopper Cylinder Model: MSBS Specification

Pressure
1.5-7 bar

Wall Thickness
6 mm

Capacity
20-80 kg stopping force

Temperature
-10°C to +70°C

Material
Aluminium Alloy Body with SS Rod

Structure
Double acting piston cylinder

Power
Pneumatic

Dimensions
90 mm diameter x 160 mm length

Max. Stroke
50 mm

Shaft Diameter
20 mm

Seals Type
Nitrile Rubber (NBR)

Rod
Stainless Steel (High-Strength)

Weight
3.8 kg

Product Code
MSBS Series

Port Size
G1/8\\

Cushion Type
Adjustable air cushion

Operation Mode
Auto/Manual

Mounting Type
Flange or Foot mounting available

Surface Treatment
Anodized body, chrome-plated shaft

End Style
Flat or Roller

Applicable Medium
Filtered, lubricated air

Repeatability
0.1 mm

Installation
Horizontal or Vertical

Stopper Cylinder Model: MSBS Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
1 Week

Stopper Cylinder Model: MSBS About

Stopper Cylinder

Model: MSBS

Tube I.D. 20~50 (mm). Double acting with spring,Shockless stopper,Operating pressure range:2~9.9 kgf/cm2,Proof pressure:15 kgf/cm2,Ambient temperature 5~ 60 (No freezing)Standard with magnet.

Specifications :

Operation type	Double acting, Direct stopper
Standard stroke	20-10, 32-20, 50-30
Medium	Air
Operating pressure range	2-9.9 kgf/cm2
Proof pressure	15 kgf/cm2
Ambient temperature	5~ 60 (No freezing)
Lubrication	Not required
Cushion	With rubber cushion pad
Magnet	With magnet
Sensor switch	RCA for 50, RCB
Sensor switch holder	HS
Weight	192g, 1850g

Versatile Mounting and Operation

Choose between flange or foot mounting for the MSBS Series Stopper Cylinder, making it adaptable to a wide range of installations. The cylinder can be set up for horizontal or vertical operation and offers both automatic and manual control modes, increasing application flexibility in various industrial environments.

Durable Build for Demanding Jobs

Constructed with an anodized aluminium alloy body and a chrome-plated, high-strength stainless steel shaft, this stopper cylinder withstands heavy use while minimizing wear. Nitrile rubber (NBR) seals offer excellent resistance to high pressure and oil, resulting in lower maintenance needs and longer service life.

Precision Stopping and Easy Adjustment

The MSBS model is engineered for precise operations, featuring repeatability of 0.1 mm and adjustable air cushioning for controlled deceleration. With max stroke up to 50 mm and a stopping force capacity from 20 to 80 kg, it ensures safety and smooth performance in production lines.

FAQs of Stopper Cylinder Model: MSBS:

Q: How do I install the MSBS Series Stopper Cylinder in my assembly line?

A: The MSBS Series Stopper Cylinder can be installed using either flange or foot mounting, based on your setup. It accommodates both horizontal and vertical positioning. Carefully secure the cylinder according to the chosen mount, ensuring filtered, lubricated air supply and proper alignment for reliable operation.

Q: What are the benefits of the adjustable air cushion in this cylinder?

A: The adjustable air cushion allows you to fine-tune the cylinders deceleration at the end of stroke, reducing mechanical shock and noise. This enhances the lifespan of both the cylinder and connected equipment while improving overall operational safety and consistency.

Q: When should I use the auto versus manual operation modes?

A: Automatic operation is ideal for repetitive, high-volume tasks, providing efficient and consistent performance. Manual mode is beneficial during maintenance, setup, or when precise, human-controlled stopping is necessary. Select the mode based on your workflow requirements.

Q: Where can the MSBS Series Stopper Cylinder be applied?

A: This cylinder is suitable for industrial automation, conveyors, and production lines requiring controlled stopping of goods or vehicles. Its design and mounting options make it compatible with various industrial settings, especially where filtered, lubricated air is available.

Q: What process conditions ensure optimal performance of the cylinder?

A: For best results, operate the cylinder at pressures between 1.5 and 7 bar using filtered, lubricated air. Maintain ambient temperatures from -10C to +70C, and check that proper surface treatment and seal integrity are intact for longevity and reliability.

Q: How does the high-strength stainless steel rod and anodized body improve durability?

A: The anodized aluminium body is corrosion-resistant, while the chrome-plated, high-strength stainless steel rod resists wear and bending. These materials together provide robust performance and extended service life in demanding industrial environments.
