Solenoid Valve MVSC Series Model: MVSD-180

Get a Price/Quote

MOQ : 1 Piece

Solenoid Valve MVSC Series Model: MVSD-180 Specification

Coating
None

Load Capacity
Medium

Size
Compact

Accuracy
High

Thread Type
Standard

Machine Type
Solenoid Valve

Shape
Rectangular

Weight
Lightweight

Method
Electromechanical

Type
MVSC Series Model MVSD-180

Material
Aluminum Alloy

Tolerance
Precise

Surface
Smooth

Use
Control Air Flow

Application
Industrial Automation

Usage & Applications
Pneumatic Control Systems

About Solenoid Valve MVSC Series Model: MVSD-180

Solenoid Valve MVSC Series

Model: MVSD-180

Body width:18mm, Port size:PT 1/8, Operating pressure range:1.5~8 kgf/cm2, Proof pressure:10 kgf/cm2,Flow:400~533Nl/min(5/3)

Specifications :

Body width	18mm
Bore No.	6A
Port size	PT 1/8
No. of port	3,5
No. of position	2,3
Medium	Air
Operating pressure range	1.5~8kgf/cm2
Proof pressure	10kgf/cm2
Flow	400~533Nl/min(5/3)
Effective orifice	9~12mm2
Response time	30ms
Ambient temperature	5~ 50 (No freezing)
Voltage	AC110V, 220V (50/60)Hz, DC24V
Power consumption	AC=3.7/ 3.1VA, DC=2.9W
Available voltage range	10%
Insulation class	F class
Weight	120g~190g

High-Precision Air Flow Control

The MVSD-180 solenoid valve delivers highly accurate pneumatic control, critical for advanced machinery. With precise tolerance and medium load capacity, it ensures optimal functioning in demanding industrial automation scenarios, offering users consistent performance and minimal maintenance requirements.

Compact Design for Versatile Applications

Engineered with a compact, lightweight, and rectangular aluminum alloy body, the MVSD-180 is ideal for installations with limited space. Its standard threading, smooth surface, and CNC compatibility allow for easy, secure integration into pneumatic control systems across various sectors.

FAQs of Solenoid Valve MVSC Series Model: MVSD-180:

Q: How does the MVSD-180 solenoid valve improve pneumatic control systems?

A: The MVSD-180 solenoid valve enhances pneumatic control systems by providing precise and reliable control of air flow, supporting high-accuracy operations, which is essential for industrial automation and CNC machinery.

Q: What are the key benefits of using the MVSD-180 in industrial automation?

A: Key benefits include compact size for space-saving integration, precise air flow control, durable aluminum alloy construction, lightweight for easy handling, and compatibility with standard threads and CNC systems, making it efficient for modern automation needs.

Q: When is the MVSD-180 recommended for use?

A: The MVSD-180 is ideal for deployment when precise, high-accuracy control of air flow is required in pneumatic control systems, especially in industrial automation environments where consistent performance and reliability are crucial.

Q: Where can the MVSD-180 solenoid valve be installed?

A: This solenoid valve is designed for use in pneumatic control systems within industrial facilities, automation lines, and systems requiring CNC compatibility. Its compact shape allows installation in confined spaces and machinery with intricate setups.

Q: What process is followed to integrate the MVSD-180 into existing systems?

A: To integrate the MVSD-180, ensure compatibility with your pneumatic systems specifications, connect using the standard thread types provided, and securely mount the lightweight, compact valve into the designated area for efficient air flow control.

Q: How is the accuracy and tolerance of the MVSD-180 beneficial for users?

A: The high accuracy and precise tolerance of the MVSD-180 guarantee consistent and stable control of air flow, minimizing deviations and ensuring optimal performance, which is particularly beneficial for precision-driven industries.
