SKF Tandem linear bearing units LTBR

Price 1000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SKF Tandem linear bearing units LTBR Specification

Retainer
Polyamide/Plastic retainer

Lubrication Type
Factory pre-lubricated with grease

Cage Material
Polyamide cage

Thickness
Depends on size, commonly 30 mm to 100 mm

Precision Rating
ISO class 6 and 7

Inside Diameter
12 mm to 50 mm

Bearing Type
LTBR Linear Ball Bearing Unit

Material
Bearing steel/Polymer composite housing

Structure
Tandem linear bearing units

Seals Type
Double-lip contact seals

Number Of Rows
4-row

Bore Size
12 mm to 50 mm

Outside Diameter
22 mm to 80 mm

Limiting Speed
up to 4,000 rpm (varies by size)

Load Capacity
High radial load capacity, suitable for heavy-duty applications

Installation
Easy to install with mounting bolts

Compliance
Conforms to DIN ISO 10285

Replaceable Inserts
Yes, linear bearing insert replaceable

Noise Level
Low operating noise

Guiding Accuracy
High-precision guidance with minimal play

Mounting
Interchangeable with standard housing units

Application
Automation systems, machine tools, robotics, packaging equipment

Operating Temperature
-20C to +80C

Housing Type
Anodized aluminium, corrosion resistant

Self-aligning Facility
Provided for minor misalignments

SKF Tandem linear bearing units LTBR Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Week

Delivery Time
1 Week

About SKF Tandem linear bearing units LTBR

F_wA C D_aH H₁H₂H₃J J₁C C₀
				0,01
mm													N		kg
12	60	28	19	17	33	16	11	29	35	40	4.3	M 5	1,140	1,020	0.17	LTB	12-2LS
16	65	30	24	19	38	18	11	34	40	45	4.3	M 5	1,530	1,270	0.22	LTB	16-2LS
20	65	30	28	23	45	22	13	40	45	53	5.3	M 6	1,900	1,600	0.31	LTB	20-2LS
25	85	40	35	27	54	26	18	48	55	62	6.6	M 8	3,450	3,150	0.54	LTB	25-2LS
30	105	50	40	30	60	29	18	53	70	67	6.6	M 8	5,200	5,400	0.80	LTB	30-2LS
40	125	60	52	39	76	38	22	69	85	87	8.4	M 10	9,000	9,000	1.57	LTB	40-2LS
50	145	70	62	47	92	46	26	82	100	103	10.5	M 12	11,400	12,700	2.51	LTB	50-2LS

High Precision and Durability

SKF LTBR tandem linear bearing units are engineered for precision guidance with minimal play. Anodized aluminium housing ensures excellent corrosion resistance and stability in severe conditions. The 4-row design enhances radial load capabilities, making them ideal for heavy-duty automation and machinery.

Versatile and Easy Installation

These bearing units feature interchangeable housing, simplifying replacement tasks. Installation is straightforward with standard mounting bolts, and factory pre-lubrication saves time by reducing maintenance needs. The self-aligning facility compensates for minor misalignments, ensuring smooth operation.

Performance for Demanding Applications

LTBR linear bearing units cater to automation, machine tools, robotics, and packaging equipment. Their double-lip seals prevent contaminant ingress and their wide range of bore sizes provides a solution for various system requirements. They are compliant with ISO standards for international compatibility.

FAQs of SKF Tandem linear bearing units LTBR:

Q: How do I install SKF LTBR tandem linear bearing units?

A: Installation is straightforward; the units are designed to be interchangeable with standard housings and require only mounting bolts. The self-aligning feature helps accommodate minor misalignments, making the setup process simple and efficient.

Q: What applications are suitable for these linear bearing units?

A: SKF LTBR tandem linear bearing units are well-suited for automated systems, machine tools, robotics, and packaging equipment. They provide high-precision guidance and can handle heavy radial loads, making them ideal for demanding industrial environments.

Q: When should the bearing insert be replaced?

A: The linear bearing insert should be replaced when you notice increased play, noise, or reduced guiding accuracy. Since these units feature replaceable inserts, maintenance is easy and extends the bearings service life without needing to replace the entire unit.

Q: Where can these bearings be used with respect to environmental conditions?

A: These units operate effectively within temperatures ranging from -20C to +80C and feature corrosion-resistant housings, making them suitable for a wide range of industrial environments, including those with exposure to moisture or frequent temperature variations.

Q: What is the process for maintaining SKF LTBR linear bearing units?

A: The bearings are factory pre-lubricated with grease, minimizing maintenance requirements initially. For ongoing care, inspect for occasional re-lubrication and check seals and inserts during scheduled maintenance.

Q: How does the self-aligning facility benefit users?

A: The self-aligning feature compensates for minor misalignments during installation, ensuring optimal linear motion and reducing the risk of premature wear or failure, thus improving reliability in operation.

Q: What are the noise and compliance characteristics of these units?

A: SKF LTBR linear bearing units are designed for low-noise operation, making them suitable for precision machinery. They are manufactured to conform with DIN ISO 10285 standards, ensuring quality and compatibility with international systems.
