Rotary Actuator Model: MCRB

Get a Price/Quote

MOQ : 1 Piece

Rotary Actuator Model: MCRB Specification

Weight
2-4 kg (vary as per model)

Load Capacity
Up to 1000 Nm

Accuracy
High Repeatability ±0.1°

Size
Customized/Standard (as per order)

Method
Hydraulic or Pneumatic

Thread Type
Metric

Coating
Hard Anodized

Machine Type
Rotary

Shape
Cylindrical

Hardness
50-60 HRC

Type
Rotary Actuator

Material
Aluminum Alloy

Tolerance
±0.05 mm

Surface
Anodized/Polished

Use
Industrial Automation

Application
Rotational Motion in Machinery

Usage & Applications
Robotics, Conveyors, Automated Systems

End Cap Material
Aluminum

Control Method
Double Acting

Mounting Type
Flange or Foot Mount

Rotation Angle
90, 180, 270, 360 (Optional)

Maintenance
Low, Easily Serviceable

Seal Material
Nitrile Rubber (NBR)

Max Operating Temperature
80C

Port Size
G 1/8\\

Color
Silver & Black

Operating Pressure
2-8 bar (Pneumatic)

Model Number
MCRB

Rotary Actuator Model: MCRB About

Rotary Actuator

Bore size: 16~32 (mm). The swing motion with twin-piston and rack-pinion driving. Adjustable swing angle(0~190), three Body mounting mode .

Features

Twin rack and pinion fitted as standard.
Can be adjusted between 0 and 190 degrees.
Simple mounting of sensors.
Magnetic as standard.

Specifications :

Acting type	Double acting
Bore size	16,20,25,32
Port size	PT1/8
Medium	Air
Operating pressure range	1~9.9 kgf/cm2
Proof pressure	15 kgf/cm2
Ambient temperature	5~ 60 (No freezing)
Lubrication	Not required
Cushion	NBR spacer
Stable rotation time	0.2~1.0 s/90
Allowable kinetic energy	Cushion pad: 0.007J, 0.040J, 0.081J, 0.32JCushion: 0.039J, 0.116J, 0.294J, 1.6J
Sensor switch	RCD
Weight	0.7~3.07 kg

Engineered for Industrial Precision

The MCRB Rotary Actuator stands out for its unmatched accuracy and robust build. With a tolerance of 0.05 mm and high repeatability of 0.1, it addresses critical needs in industrial automation. Its construction with an aluminum alloy body and hard anodized coating guarantees long-lasting performance under tough operating conditions. Suitable for both customized and standard sizes, this actuator integrates seamlessly with a range of machinery.

Versatile Installation and Application

Designed with flexibility in mind, the MCRB Rotary Actuator offers flange or foot mount options to accommodate diverse installation requirements. The actuator is ideal for robotics, conveyors, and automated systems, and its double-acting control enables precise movement in rotational applications. Its compact cylindrical shape and metric threading ensure compatibility with standard machinery interfaces.

Reliable Performance with Easy Maintenance

This actuator operates efficiently within a pressure range of 2 to 8 bar and temperatures up to 80C, making it adaptable to various industrial environments. NBR sealing ensures low maintenance and minimizes downtime, while the lightweight but sturdy design (24 kg depending on model) facilitates easy handling and service. Distributors, suppliers, and importers across India trust the MCRB model for industrial reliability.

FAQs of Rotary Actuator Model: MCRB:

Q: How do I select the appropriate rotation angle for the MCRB Rotary Actuator?

A: Selection depends on your applications motion requirements. The MCRB offers options of 90, 180, 270, or 360. Choose the smallest angle that meets your machines needs for efficiency and faster cycle times.

Q: What installation methods are available for the MCRB Rotary Actuator?

A: The actuator supports both flange and foot mounting, allowing flexible integration into new or existing setups. Follow the provided installation guide to ensure secure and proper attachment.

Q: Where can the MCRB Rotary Actuator be used?

A: It is designed for use in industrial automation, particularly in machinery requiring controlled rotational movementsuch as robotics, conveyors, and automated assembly lines.

Q: What are the benefits of the actuators double acting control method?

A: Double acting control allows for precise bi-directional movement, improving position accuracy and speed in automation tasks. It enables reliable operation even under varying load conditions.

Q: How is maintenance handled for the MCRB Rotary Actuator?

A: Thanks to its NBR seals and polished anodized surfaces, maintenance is minimal. The actuator is engineered for easy servicing, minimizing operational downtime and associated costs.

Q: What is the process to order the actuator in a customized size?

A: Contact your distributor, supplier, or importer in India with your specific size requirements. Standard and custom sizes are available to fit diverse applications by request.
