Roller Plunger Valve

Get a Price/Quote

MOQ : 1 Piece

Roller Plunger Valve Specification

Method
Mechanical actuation

Weight
120 grams

Thread Type
Standard Metric Threads

Size
Approx. 80 mm x 25 mm x 30 mm

Load Capacity
Designed for signal currents up to 0.5 A

Machine Type
Industrial Automation Machinery

Hardness
45-50 HRC (plunger)

Coating
Electroplated corrosion-resistant coating

Accuracy
Repeatability 0.02 mm

Shape
Rectangular with roller plunger projection

Type
Roller Plunger Valve

Material
Zinc Alloy Body, Stainless Steel Plunger

Tolerance
0.05 mm

Surface
Polished finish

Use
Actuating pneumatic or hydraulic devices

Application
Automation systems, machinery, conveyors

Usage & Applications
Position detection, limit switching, automatic equipment

Mounting Type
Base Mounting

Response Time
<20 ms

Degree of Protection
IP65

Contact Type
1 NO + 1 NC

Operating Temperature Range
-10C to +60C

Switching Frequency
Up to 120/min

Service Life
>5 million cycles

Operating Pressure
1.5 to 8 bar

Roller Material
Polyacetal (POM)

Reset Type
Spring Return

Connection Port Size
M5 or 1/8 BSP

Plunger Stroke
4 mm

Medium
Air (filtered and unlubricated)

About Roller Plunger Valve

Roller Plunger Valve

Spring return type, Port size:PT1/4,PT 3/8, Port no.:5, Position:2, Operating pressure range:0~9 kgf/cm2

Specifications :

Acting	Spring return type
Port size	PT 1/4, PT 3/8
No. of port	5
No.of position	2
Medium	Air
Operating pressure range	0~9 kgf/cm2
Ambient temperature	0~ 60
Weight	353 g, 352 g
Model	ACT-405

Precision Actuation for Industrial Systems

Engineered for accuracy and durability, the Roller Plunger Valve provides repeatability within 0.02 mm and supports up to 120 switching operations per minute. Its compact and robust design allows for base mounting in confined spaces, making it ideal for automation systems, conveyors, and machinery requiring reliable position detection and limit switching.

Robust Build and Extended Service Life

Constructed with a zinc alloy body, stainless steel plunger, and polyacetal roller, the valve boasts a polished, electroplated finish for corrosion resistance. With over 5 million cycles of service life and an IP65 rating, it withstands dust, moisture, and harsh industrial conditions, ensuring long-term, maintenance-free performance.

FAQs of Roller Plunger Valve:

Q: How does the Roller Plunger Valve function within automation systems?

A: This valve is mechanically actuated when a moving part presses the roller plunger, triggering the internal contacts (1 NO + 1 NC) to change state. Its used for position detection, limit switching, and sending signals to pneumatic or hydraulic devices in automation equipment.

Q: What environments are suitable for installing this valve?

A: The valve suits indoor industrial environments requiring IP65 protection, such as automated machinery, conveyors, and factories, operating reliably from -10C to +60C and withstanding dusty or mildly wet conditions.

Q: When should I choose the Roller Plunger Valve with polyacetal roller and zinc alloy body?

A: Select this valve when you require high cycling life, precision repeatability (0.02 mm), and corrosion resistance for automation tasks involving filtered, unlubricated air at pressures from 1.5 to 8 bar.

Q: Where is this valve typically mounted, and what connection sizes are supported?

A: The valve uses a base mounting configuration for stable installation on machinery frames or panels. It supports connection port sizes of either M5 or 1/8 BSP for flexible integration into pneumatic circuits.

Q: What is the process for using or installing this valve in automation equipment?

A: Mount the valve securely using its base mounting holes, connect the selected port (M5 or 1/8 BSP) to your air supply, and wire the contacts into your control system. Position the roller in the motion path where actuation must occur for reliable switching.

Q: Why is this valve beneficial for position detection in automated machinery?

A: It offers rapid response (<20 ms), excellent repeatability, and a long service life, ensuring consistent and accurate detection even in fast-moving industrial processes. The spring return provides automatic reset, supporting high-frequency cycling up to 120/min.
