NSK Lm Guides 15 20 25 30 35 45 55 65

1000.00 - 10000.00 INR/Piece

Get a Price/Quote

Product Details:

Thickness Standard block height, varies by type
Weight Varies per size; approx. 0.25 kg to 24 kg
Material Bearing Steel, Stainless Steel
Ball Bearing Type Yes
Roller Bearing Type Yes
Bushes Type Linear Bushes
Structure Linear Motion Guide Rail and Block
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

NSK Lm Guides 15 20 25 30 35 45 55 65 Price And Quantity

Minimum Order Quantity 1 Piece
Price Range 1000.00 - 10000.00 INR/Piece

NSK Lm Guides 15 20 25 30 35 45 55 65 Product Specifications

Limiting Speed 2~5 m/s
Thickness Standard block height, varies by type
Bushes Type Linear Bushes
Weight Varies per size; approx. 0.25 kg to 24 kg
Roller Bearing Type Yes
Ball Bearing Type Yes
Outside Diameter Varies by size/module
Bore Size 15, 20, 25, 30, 35, 45, 55, 65 mm
Seals Type End seal, side seal available
Load Capacity Up to 210 kN (varies per size)
Material Bearing Steel, Stainless Steel
Inner Diameter 15 mm to 65 mm
Structure Linear Motion Guide Rail and Block

NSK Lm Guides 15 20 25 30 35 45 55 65 Trade Information

Supply Ability 1000 Piece Per Month
Delivery Time 1 Days

Product Description

NSK Lm Guides 15 20 25 30 35 45 55 65

Item Code: LmGuides

Nsk Japan Is one of the leader in Linear guides,lm guides,linear guide ways, and have many products to suitable to industrial needs.

High Precision Performance

Engineered with multiple precision grades (C, H, P, SP, and UP), NSK LM Guides deliver superior accuracy and stability essential for advanced industrial applications. They ensure precise linear motion, making them indispensable in sectors such as robotics, CNC machining, semiconductors, and medical device manufacturing. Their robust design guarantees consistent performance even under demanding conditions.

Versatile Mounting and Configurations

With options for top or bottom mounting, and a comprehensive variety of block typesincluding standard, long, wide, slim, and flangedNSK LM Guides can be tailored to fit diverse installation requirements. Rail lengths are customizable up to 4 meters or more, accommodating a wide range of automation and machinery layouts for both new installations and retrofits.

Durable Construction and High Load Capacity

Manufactured from premium bearing steel or stainless steel, these guides provide exceptional strength and longevity. The system supports impressive loads, up to 210 kN, and offers limiting speeds of 2 to 5 m/s. Reliable lubrication (grease or oil) and advanced seal types ensure prolonged life and smooth operation even in challenging industrial environments.

FAQs of NSK Lm Guides 15 20 25 30 35 45 55 65:

Q: How do I select the right NSK LM Guide for my application?

A: Selecting the appropriate NSK LM Guide involves considering your required precision grade (C, H, P, SP, UP), block type (standard, long, wide, slim, flanged), mounting method, load capacity, and rail length. You should also account for the operating environment, as material options (bearing steel or stainless steel) and lubrication type (oil or grease) impact performance in specific conditions.

Q: What benefits do NSK LM Guides offer for CNC machines and automation systems?

A: NSK LM Guides enhance CNC machines and automation setups by ensuring high-precision movement, load stability, and consistent performance. Their customizable options, high load capacity (up to 210 kN), and advanced sealing offer reliability, minimal maintenance, and suitability for demanding continuous operation.

Q: When should I choose a heavier preload or higher precision grade for my guide?

A: A heavier preload is ideal when you require greater rigidity and minimal deflection under load, such as in high-accuracy machining or precision automation. Higher precision grades (P, SP, UP) should be chosen for applicationslike semiconductor fabrication or high-precision medical deviceswhere minimal movement error is critical.

Q: Where can I source NSK LM Guides in India?

A: NSK LM Guides are distributed by authorized importers, suppliers, and distributors throughout India. They are available in major industrial markets and can also be sourced through specialized bearing and automation equipment suppliers who offer technical support and customization services.

Q: What is the process for customizing rail length or selecting block type?

A: To customize a rail or choose a specific block type, consult with your NSK distributor or supplier. Provide key details such as application, load requirements, and desired configurations. The supplier will guide you through options, including rail length, block design, and mounting solutions, ensuring optimal performance for your project.

Q: How does lubrication type affect the operation and maintenance of these guides?

A: Lubricationeither grease or oilis essential for smooth movement, reduced friction, and prolonged lifespan of NSK LM Guides. Grease offers longer intervals between maintenance duties, whereas oil may be suitable for high-speed or cleanroom applications, such as in semiconductors or medical devices. The proper choice of lubricant ensures reliable, low-wear operation.

Q: What are the advantages of using linear motion guide rails with ball or roller bearings?

A: Linear motion guide rails with ball or roller bearings provide low-friction, high-precision movement, supporting heavy loads while maintaining alignment and minimizing wear. This translates to quieter operation, reduced energy consumption, and improved accuracy in a wide range of industrial automation and machinery applications.
