NAMUR Solenoid Valve MVSN Series Model: MVSN-300

Send Inquiry

Request To Call Back

NAMUR Solenoid Valve MVSN Series Model: MVSN-300

Get a Price/Quote

MOQ : 1 Piece

NAMUR Solenoid Valve MVSN Series Model: MVSN-300 Specification

Thread Type
Namur standard threaded ports

Weight
Approximately 480 g

Shape
Rectangular with NAMUR interface

Machine Type
Pneumatic Actuator Accessory

Accuracy
High repeatability (<1 ms response variance)

Load Capacity
Up to 8 bar (116 psi)

Coating
Anodized

Hardness
65-75 Shore A

Size
1/4 port size

Method
Electromagnetic solenoid drive

Type
NAMUR Solenoid Valve

Material
Aluminium body, Stainless steel internals

Tolerance
±5%

Surface
Smooth anodized finish

Use
Process automation control

Application
Pneumatic systems, actuator control

Usage & Applications
Industrial automation, valve actuation

Seal Material
NBR (Buna-N)

Power Consumption
2.5W (DC), 6VA (AC)

Working Pressure
1.5 to 8 bar

Response Time
<20 ms

Flow Rate (Cv)
~0.7

Protection Class
IP65 with coil

Operating Voltage
24V DC / 230V AC (optional)

Temperature Range
-10°C to +80°C

Mounting
NAMUR interface mounting

Manual Override
Yes

Operation
Direct acting, 5/2 way

Media
Filtered, lubricated or non-lubricated air

Connection Type
NAMUR standard mounting plate

Series
MVSN

Coil Insulation Class
Class F

Model
MVSN-300

NAMUR Solenoid Valve MVSN Series Model: MVSN-300 About

NAMUR Solenoid Valve

Model: MVSN-300

Body width:30mm,Port size:PF 1/4(poreA,R1,R2),Operating pressure range:2~7 kgf/cm²,Proof pressure:10.5 kgf/cm²

Specifications :

Body width

30mm

Bore No.

Port size

PF 1/4 (port A, R1, R2)

No. of port

No. of position

2,3

Medium

Air

Operating pressure range

2~7 kgf/cm²

Proof pressure

10.5 kgf/cm²

Effective orifice

30~35mm²

Response time

50 ms

Ambient temperature

5~50 (No freezing)

Voltage

AC110V, 220V (50/60)Hz, DC24V

Power consumption

AC=6/4.9VA, DC=2.5W

Available voltage range

10%

Insulation class

F class

Weight

422g~764g

Advanced Performance and Versatility

Designed for process automation and industrial environments, the MVSN-300 NAMUR Solenoid Valve enables precise, rapid control of pneumatic actuators. It accommodates a broad pressure range and offers seamless mounting via the NAMUR interface, making integration quick and reliable. The rectangular, anodized finish ensures wear resistance and longevity, even in demanding conditions.

Reliable Construction and Safety Features

This solenoid valves aluminium body and stainless steel internals provide superior durability. The NBR sealscombined with anodized surface protectionguarantee excellent compatibility with filtered, lubricated, or non-lubricated air. IP65-rated when coil-equipped, it resists dust and water, while the built-in manual override supports maintenance and emergency operations.

FAQs of NAMUR Solenoid Valve MVSN Series Model: MVSN-300:

Q: How is the MVSN-300 NAMUR solenoid valve typically installed?

A: The MVSN-300 utilizes a NAMUR standard mounting plate and threaded ports, allowing direct installation onto compatible pneumatic actuators and systems without additional adapters. This greatly simplifies integration and maintenance processes.

Q: What is the typical application for the MVSN-300 solenoid valve in process automation?

A: This valve is ideally used to control actuator positions in automated pneumatic systems, offering high repeatability and fast response times required by industrial processes such as valve actuation and motion control.

Q: When should I choose the MVSN-300 over other solenoid valves?

A: Choose the MVSN-300 when a direct acting, 5/2 way functionality is required alongside fast response (<20 ms), rugged construction, and NAMUR mounting compatibility. Its suitable when operating pressures are between 1.5 to 8 bar and enhanced durability matters.

Q: Where can the MVSN-300 valve be used effectively?

A: The valve is best employed in industrial automation scenarios, including process control, pneumatic actuator management, and environments requiring resistance to dust and moisture, thanks to its IP65 protection and robust build.

Q: What are the benefits of using a NAMUR interface solenoid valve like the MVSN-300?

A: A NAMUR interface enables universal compatibility and quick mounting with standard actuator systems, reducing installation time and ensuring consistent performance across diverse pneumatic setups.

Q: How does the manual override feature assist operation or maintenance?

A: The manual override allows the actuator to be operated independently of electrical control, facilitating safe maintenance, manual adjustments, or troubleshooting without interrupting system pressure or integrity.

Q: What media types are compatible with this solenoid valve?

A: The MVSN-300 is compatible with filtered, lubricated, or non-lubricated air, making it flexible for a range of pneumatic system requirements typically found in industrial automation.
