MINDMAN MP1 / MP10 series

Get a Price/Quote

MOQ : 1 Piece

MINDMAN MP1 / MP10 series Specification

Shape
Rectangular Module

Load Capacity
24V DC, Max. 50mA

Method
Non-contact Detection

Coating
Anodized Aluminium

Size
MP1: 28x15x7mm / MP10: 34x15x10mm

Machine Type
Industrial Cylinder

Accuracy
High Repeatability, Sensing deviation 0.1mm

Weight
MP1: Approx. 10g / MP10: Approx. 15g

Type
Magnetic Proximity Sensor

Material
Aluminum Body with Electronic Components

Tolerance
0.01mm

Surface
Anodized or Powder Coated

Use
Pneumatic Systems

Application
Pneumatic Position Sensing

Usage & Applications
Cylinders in Industrial Automation

Vibration Resistance
10-55Hz, amplitude 1.5mm

Ambient Temperature Range
-10C to +70C

Wire Length
2m Standard

Response Time
1ms

Supply Voltage
5-240V AC/DC (MP1), 10-30V DC (MP10)

Shock Resistance
300m/s (30G)

Insulation Resistance
100M or more (at 500VDC)

Output Type
Reed Switch (MP1), Solid State (MP10)

Contact Rating
50mA Max.

Protection
IP67

Mounting Method
Bracket or Screw Mountable

Indicator
LED Display

Sensing Object
Magnet inside piston

MINDMAN MP1 / MP10 series About

MP1 series (Pressure Switch)
MODEL NO.	Description	UNIT PRICE
MP1-1-01-01	Vacuum, NPN 1 outpu, 1m
MP1-1-02-01	Vacuum, PNP 1 outpu, 1m
MP1-1-03-01	Vacuum, NPN 2 output, 1m
MP1-2-01-01	Low pressure, NPN 1 output, 1m
MP1-2-02-01	Low pressure, PNP 1 output, 1m
MP1-2-03-01	Low pressure, NPN 2 output, 1m
MP1-3-01-01	Positive, NPN 1 outpu, 1m
MP1-3-02-01	Positive, PNP 1 outpu, 1m
MP1-3-03-01	Positive, NPN 2 output, 1m

Versatile Voltage & Reliable Performance

MP1 and MP10 adapt to various automation environments with a supply voltage range of 5240V AC/DC for MP1 and 1030V DC for MP10. Fast response times (1ms) and long-lasting builds provide non-contact, high-precision position sensing for industrial pneumatic cylinders.

High Durability For Industrial Automation

A robust aluminum body with anodized or powder-coated surface and IP67 protection ensure longevity in harsh environments. These sensors withstand vibration, shock, and extreme temperatures, making them reliable for continuous operation in industrial settings.

Simple Setup and Maintenance

With a 2m standard wire and options for bracket or screw mounting, installation is straightforward. The LED indicator offers clear operational feedback, while high insulation resistance and shock resistance simplify ongoing maintenance.

FAQs of MINDMAN MP1 / MP10 series:

Q: How do I install the MINDMAN MP1 or MP10 sensor on a pneumatic cylinder?

A: You can mount the MP1 and MP10 sensors using either brackets or screws, depending on your cylinder type and space constraints. The standard 2-meter wire length offers flexibility for routing connections to your control panel.

Q: What is the primary benefit of using these sensors in pneumatic systems?

A: The main advantage is precise, non-contact detection of piston position, which enhances automation efficiency and system reliability due to high repeatability (0.01mm) and rapid response times (1ms).

Q: When should I choose MP1 over MP10 or vice versa?

A: Select MP1 if your system requires a sensor compatible with both AC and DC voltages and a reed switch output. Opt for MP10 when working with 1030V DC supplies and you prefer solid state output for higher durability under frequent switching.

Q: Where can these sensors be used in industrial automation?

A: These sensors are designed for mounting on pneumatic cylinders in various automation setups, including production lines, packaging machinery, and material handling systems across different industry sectors.

Q: What kind of objects do these sensors detect?

A: MP1 and MP10 detect the magnet embedded within the piston of a pneumatic cylinder through non-contact proximity sensing, facilitating accurate position feedback.

Q: How do the LED displays on the MP1 and MP10 assist during operation?

A: The built-in LED indicator provides quick visual confirmation of the sensors status, allowing maintenance personnel to easily monitor operation and troubleshoot issues.
