MINDMAN MCG3 series

Get a Price/Quote

MOQ : 1 Piece

MINDMAN MCG3 series Specification

Load Capacity
Suitable for medium-duty loads

Hardness
High

Accuracy
High precision positioning

Machine Type
Automation Equipment

Thread Type
Metric

Cutting Speed
N/A (Not a cutting component)

Shape
Rectangular

Coating
Anodized

Weight
Varies by model (e.g. MCG3-16: ~0.19kg)

Method
Double Acting

Size
16 mm, 20 mm, 25 mm, 32 mm, 40 mm, 50 mm (Bore Size Options)

Type
Compact Guide Cylinder

Material
High Grade Aluminum Alloy

Tolerance
0.01 mm

Surface
Polished

Use
Pneumatic Cylinder Guide

Application
Industrial Automation

Usage & Applications
Positioning, Pushing, Lifting, Clamping

Mounting Methods
Basic, Flange, Foot, and Side mounting

Cushion Type
Rubber bumper

Piston Rod Material
Stainless Steel

Operating Temperature
-5C to 60C

Series
MCG3

Action Type
Double acting with built-in guide

Operating Pressure
0.11.0 MPa

End Cap Material
Aluminum

Manufacturing Standard
ISO standard compliant

Port Size
M5 x 0.8 (for 16), Rc1/8 (for other sizes)

Lubrication
Not required (maintenance-free)

Guide Type
Linear ball bushing guide

Seal Material
NBR

Stroke Range
10 mm to 100 mm

About MINDMAN MCG3 series

MCG3 series

TUBE I.D.

TYPE

STROKE= 30mm

STROKE= 50mm

STROKE= 75mm

STROKE= 100mm

TUBE I.D.

TYPE

STROKE= 30mm

STROKE= 50mm

STROKE= 75mm

STROKE= 100mm

TUBE I.D.

TYPE

STROKE= 30mm

STROKE= 50mm

STROKE= 75mm

STROKE= 100mm

Precision Performance in Industrial Automation

The MCG3 series is engineered for medium-duty load applications that demand accuracy and repeatability. Its specialized linear ball bushing guide minimizes friction while maintaining positioning precision, critical for automation environments such as assembly lines, machine positioning, and precision handling. The compact design, high-grade materials, and robust construction contribute to optimal performance and long service life.

Flexible Mounting and Easy Integration

With basic, flange, foot, and side mounting methods, the MINDMAN MCG3 series can be seamlessly integrated into diverse automation equipment setups. The availability of multiple bore sizes and port options enables compatibility with varied system requirements. Maintenance-free operation and adjustable stroke range make it suitable for rapid installation and hassle-free long-term use in industrial environments.

FAQs of MINDMAN MCG3 series:

Q: How is the MINDMAN MCG3 series pneumatic cylinder guide installed in automation equipment?

A: The MCG3 series supports easy installation using multiple mounting methods: basic, flange, foot, or side mounting. This ensures compatibility with different automation setups, enabling flexible placement within machinery.

Q: What types of industrial tasks can the MCG3 cylinder guide be used for?

A: It is ideal for a range of automation tasks such as positioning, pushing, lifting, and clamping, thanks to its compact design, medium load capability, and high precision.

Q: When is lubrication required for the MCG3 series operation?

A: Lubrication is not required for this cylinder guide. It uses a linear ball bushing guide and high-quality seals for maintenance-free operation throughout its service life.

Q: Where should the MCG3 series be used for optimal results?

A: It should be used in industrial automation systems requiring compact actuators, such as assembly lines, robotic positioning, and environments demanding high accuracy and medium-duty load handling.

Q: What is the process of selecting the correct bore size for my application?

A: Select the bore size (16 mm50 mm) based on the load capacity, required stroke length, and available space in your equipment. Higher bore sizes accommodate heavier loads and longer strokes.

Q: How does the built-in guide benefit the accuracy of operations?

A: The integrated linear ball bushing guide ensures smooth, precise motion with minimum deflection, greatly enhancing positioning accuracy and consistency during repeated cycles.
