ABBA Linear Guides

Get a Price/Quote

MOQ : 1 Piece

ABBA Linear Guides Specification

Weight
Varies with model, approx. from 0.3kg to 2.5kg

Thickness
Varies with size, approx. 10mm to 35mm

Material
Alloy Steel / Stainless Steel

Ball Bearing Type
Caged Ball

Roller Bearing Type
Caged Roller

Bushes Type
Linear Bush

Structure
Four-Row/Two-Row Design

Seals Type
End Seal, Inner Seal, Scraper Option

Number Of Rows
2 or 4

Bore Size
16mm to 50mm

Outside Diameter
26mm to 80mm

Limiting Speed
Up to 5 m/s

Load Capacity
Dynamic up to 22,300 N

Inner Diameter
16mm to 50mm

ABBA Linear Guides Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1000 Pieces Per Month

Delivery Time
1 Days

About ABBA Linear Guides

ABBA LINEAR GUIDE WAYS

In abba linear guide ways we stock huge range we have full series of ABBA linear guide ways
Abba linear guide ways like

BC SERIES,
BR SERIES,
BM SERIES,
BC SERIES
ABB LINEAR GUIDE WAYS.

BC SERIES
CAGE INSIDE
HIGH SPEED, LOW NOISE
FREE LUBRICANT, LONG SERVICE LIFE
HEAVY LOAD CAPACITY, HIGH RIGIDITY
EQUAL LOAD CAPACITY IN FOUR DIRECTIONS

1) BCH - A AL
2) BCH - B BL
3) BCS - B BL

BR SERIES
BR SERIESm

BUILT IN LONG LIFE LUBRICATION
EQUAL LOAD CAPACITIES IN FOUR DIRECTIONS
SMOOTH RUNNING DUE TO NEW BALL RE-CIRCULATION
HIGH RIGIDITY 4 - ROW ANGULAR CONTACT
INTERNATIONAL STANDARD DIMENSION
HIGH ACCURACY LOW FRICTION LOW MAINTENACE
HIGH SPEED LOW NOISE
INTEGRAL ALL - ROUND SEALING
INTERCHANGEABILITY
ENVIRONMENT PROTECTION GREEN PRODUCTION

1) BRH - A AL
2) BRH - B BL
3) BRS - B BL BS
4) BRH - C CL
5) BRX - B
--------------------------------------------------------------------------------------------------------------

BM SERIES

SIZES IN 9mm , 12 mm , 15 mm
MODE OF STAINLESS STEEL HIGH ANTI CORROSION
FREE LUBRICANT
FIXATION WITHOUT SCREW
LOW NOISE , LONG SERVICE LIFE

1) BMC 09B
2) BMC 12 B
3) BMC 15 B

Superior Precision and Customization

ABBA Linear Guides are crafted to meet a wide range of accuracy and customization needs. With five precision grades and rail lengths that can be tailored up to 4000mm, these guides easily adapt to unique specifications, providing reliable linear motion for automation, CNC, and industrial systems.

Engineered for Versatility and Durability

Outfitted with corrosion-resistant materials and a robust HRC 58~62 hardness, ABBA linear guides excel in demanding applications. Available with either caged ball or caged roller bearings and featuring excellent sealing options, these guides minimize maintenance and maximize operational longevity even in challenging industrial settings.

FAQs of ABBA Linear Guides:

Q: How do I select the appropriate precision grade for my ABBA Linear Guide application?

A: Choosing the right precision grade (C, H, P, SP, UP) depends on your applications accuracy requirements. For high-precision CNC machines or automated equipment where tight tolerances are critical, grades SP or UP are ideal. For less demanding applications, grades C or H provide reliable performance.

Q: What is the process for ordering custom rail lengths up to 4000mm?

A: To order a custom ABBA Linear Guide rail length, specify the required length (up to 4000mm) when consulting with your distributor or supplier. The manufacturer will tailor the rail according to your exact needs, ensuring compatibility with your design specifications.

Q: When should I opt for stainless steel linear guides for corrosion resistance?

A: Stainless steel models are recommended for environments with high humidity, exposure to chemicals, or where wash-down procedures occur frequently. These corrosion-resistant options help extend service life and maintain performance in harsh conditions.

Q: What lubrication options are available, and how do they benefit linear guide operation?

A: ABBA Linear Guides support both grease and oil lubrication types. Regular lubrication reduces friction and wear, which prolongs the components lifespan, enhances movement precision, and ensures low-noise operation. Choose the lubricant based on your applications speed and load requirements.

Q: Where are ABBA Linear Guides typically used, and what are the key advantages?

A: These guides are commonly utilized in automation, CNC machinery, and a variety of industrial equipment. Key benefits include high load capacity (dynamic up to 22,300 N), customizable configurations, low rolling sound, ISO/JIS compliance, and superior interchangeability, making them versatile for diverse applications.

Q: How does the pre-drilled mounting hole design improve installation?

A: Pre-drilled mounting holes ensure consistent alignment during installation, streamline the assembly process, and reduce setup time. This feature eliminates the need for additional drilling, lowering overall installation costs and risk of fitting errors.
